HARTING 15550022701333 Edge connector (pins) 1 pc(s)
Product type
Edge connector (pins)
Connector type
right angle
CS
2.54 mm
Content
1 pc(s)
Total number of pins
2
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Terminal pin strip
- Total number of pins 2
- Content 1 pc(s)
Technical specifications
- Range: Har-flex®
- Component: Terminal strip
- Contact description: Angled
- Connection type: Reflow soldering connection (THR)
- Type of connection: Motherboard to Daughtercard; extender card
- Number of contacts: 2
- Pitch, connection side 2.54 mm
- Rated current 29 A
- Insulation resistance >1010 Ω
- Continuous resistance ≤ 25 mΩ
- Temperature limit: -55 ... +125 °C
- Mating cycles ≥ 500
- Test voltage Ueff 0.84 kV
- Insulation material group IIIa (175 ≤ CTI < 400)
- Material application: Liquid-crystal polymer (LCP)
- Colour insert: Black
- Material contacts: Copper alloy
- Contact surface: Precious metal via Ni, plug side, Sn via Ni connection side
- Material flammability class acc. To UL 94: V-0
- Designation: Power
- Pitch, plug-side 2.54 mm
- Airway: ≥0.94 mm
- Tracking distance: ≥0.94 mm printed circuit board;≥1.89 mm plug connector
- Features: Type of hold-down connection: SMT
- Rated voltage: According to IEC 60664-1
- Dimensioning surge voltage: 1.5 kV
- Pollution level: 2
- Moisture Sensitivity Level (MSL): 1 according to ECA/IPC/JEDEC J-STD-020D
- Process Sensitivity Level (PSL): R0 according to ECA/IPC/JEDEC J-STD-020D
- Coplanarity of contacts: 0.1 mm
- Notes: According to IEC 61984, this is an unencapsulated connector. The protection against electric shock must be ensured by the user through the type of installation.
- Product type
Edge connector (pins)
- Connector type
right angle
- Total number of pins
2
- CS
2.54 mm
- Nominal current
29 A
- Nominal current - rounded value
29 A
- Connection
THR
- Factory colour
Black
- Case material
PA
- Manufacturer part #
15550022701333
- Content
1 pc(s)
- Contact material
Copper alloy
- Type
15 55 002 2701 333
- Resistance
25 mΩ
- Insulation resistance
1010 Ω
Other
180 V
2
Other
-55-125 °C
Other
1.5 kV
Soldering connection
Tin
2.54 mm
2.54 mm
Liquid crystal polymer
0°/180° (horizontal)
Other
29 A
Documents & Downloads
Datasheet
Datasheet 3002741 HARTING 15550022701333 Edge connector (pins) 1 pc(s)
Datasheet 3002741 HARTING 15550022701333 Edge connector (pins) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3002741 HARTING 15550022701333 Edge connector (pins) 1 pc(s)
Description
Terminal strip, reflow solder connection (THR), rated current 29 A, contacts 2, angled copper alloy
