Name: HELU 21119-500 Data transfer cable 4 x 2 x 0.34 mm² Grey 500 m
Brand: HELU
SKU: 2826569

White cable with the inscription 'HELUKABEL® PAAR-TRONIC-Li-2YCY 4x2x0.34 QMM / 21119 CE', multiple colourful wire pairs visible.

Product type

Data transfer cable

No. of leads

8 x

Cross section (each core)

0.34 mm²

Cable features

Shielded

Flame-retardant

Twisted pair cabling (part 1)

Yes (1)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Weight 95 kg/km

Product type: Data transfer cable

No. of leads: 8 x

Cross section (each core): 0.34 mm²

Twisted pair cabling (part 1): Yes (1)

Cross section: 4 x 2 x 0.34 mm²

Cable features: Shielded
Flame-retardant

Outside Ø: 8.6 mm

Factory colour: Grey

Content: 500 m

Bend radius (no. of ODs for fixed installation): 7.5

Bend radius (no. of ODs for flexible installation): 12

Shielded: Yes

Manufacturer part #: 21119-500

Insulation material: PVC

Wire ID code: Core identification according to DIN 47100 (paired stranded), colored

Insulation: PE

Core layout: Plain copper wire, multi-strand

RoHS-compliant: Yes

Min. temperature range (flexible installation): -5 °C

Max. temperature range (flexible installation): 70 °C

Min. temperature range (fixed installation): -30 °C

Max. temperature range (fixed installation): 80 °C

Certification marks: EAC

Max. length sold by the metre: 500 m

Type: PAAR-TRONIC-Li-2YCY 4x2x0,34 GR

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2826569 HELU 21119-500 Data transfer cable 4 x 2 x 0.34 mm² Grey 500 m

Description

PE-insulated, pair-stranded data cable for interference-free signal and data transmission over great distances. The twisted pair stranded conductor reduces electrical couplings within the cable, effectively suppressing crosstalk effects. Thanks to high transmission rates, ideal for RS 422 and RS 485 interfaces. Suitable for fixed laying in dry, damp and wet rooms, but not outdoors. EMC = electromagnetic compatibility; to optimize the EMC properties, we recommend that copper braid contacts are made on both sides and over a wide area.
