Name: HELU 400145 Multicore cable 14 G 2.5 mm² + 14 G 2.5 mm² Black 100 m
Brand: HELU
SKU: 2197047

Black cable with the inscription 'HELUKABEL Load cable 1(5) G 5.0 mm² 300/500V RoHS CE', shows various internal wires.

Image similar

Product type

Multicore cable

No. of leads

14 G

Cross section (each core)

2.5 mm²

No. of leads (part 2)

14 G

Cross section (each core) (part 2)

2.5 mm²

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Multicore cable

No. of leads: 14 G

Cross section (each core): 2.5 mm²

No. of leads (part 2): 14 G

Cross section (each core) (part 2): 2.5 mm²

Cross section: 14 G 2.5 mm² + 14 G 2.5 mm²

Cable features: Cold-resistant
Flexible

Outside Ø: 16.60 mm

Factory colour: Black

Content: 100 m

Nominal voltage: 300 V

Nominal voltage U0: 500 V

Packaged: Yes

Sold per metre: No

Halogen-free: No

Shielded: No

Manufacturer part #: 400145

Insulation material: PVC

Min. temperature range (fixed installation): -40 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (flexible installation): -40 °C

Max. temperature range (flexible installation): +80 °C

Core layout: Bare copper braid

Core layout: 0.15 mm

Type: HELUEVENT 14G2,5mm²

Max. length sold by the metre: 100 m

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2197047 HELU 400145 Multicore cable 14 G 2.5 mm² + 14 G 2.5 mm² Black 100 m

Description

The extremely flexible load cables are used for high mechanical loads in professional stage and light technology as well as other load circuits. By complying with all standards for television and radio, this cable is particularly suitable for all load applications. The flexibility is achieved by the extra-fine wire structure with 0.15 mm strands. The wire insulation consists of TPE-O and the sheath insulation of TPU.
