HELU JB-500 Control lead 3 G 1.5 mm² Grey 11078 50 m
EAN:
Part number:
Item no:
Product type
Control lead
No. of leads
3 G
Cross section (each core)
1.5 mm²
Cable type
JB-500
Outside Ø
6.80 mm
Technical specifications
- Product type
Control lead
- No. of leads
3 G
- Content
50 m
- Cross section (each core)
1.5 mm²
- Cable features
Flexible
Colour-coded
Oil-resistant
chemical-resistant
Suitable for drag chains
High flexural strength
- Cable type
JB-500
- Outside Ø
6.80 mm
- Packaged
Yes
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
7.5
- Halogen-free
No
- Manufacturer part #
11078
- Factory colour
Grey
- Insulation material
PVC
- Insulation
Special PVC
- Core layout
Plain copper braid, DIN VDE 0295 Cl.5, finely stranded, BS 6360 cl.5, IEC 60228 cl.5
- Sold per metre
No
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Number-coded
No
- Test voltage
4000 V
- Cross section
3 G 1.5 mm²
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
JB-500
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2197096 HELU JB-500 Control lead 3 G 1.5 mm² Grey 11078 50 m
