HELU JB-750 Control lead 3 G 1.5 mm² Yellow 10334 100 m
EAN:
Part number:
Item no:
Product type
Control lead
No. of leads
3 G
Cross section (each core)
1.5 mm²
Cable type
JB-750
Outside Ø
7.80 mm
Datasheet (PDF)
Technical specifications
- Product type
Control lead
- No. of leads
3 G
- Content
100 m
- Cross section (each core)
1.5 mm²
- Cable features
Flexible
- Cable type
JB-750
- Outside Ø
7.80 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
7.5
- Halogen-free
No
- Manufacturer part #
10334
- Factory colour
Yellow
- Insulation material
PVC
- Insulation
Special PVC
- Core layout
Cu-blank, in accordance with BS 6360 Cl.5, IEC 60228 Class 9
- Material (details)
PVC
- Max. length sold by the metre
500 m
- Sold per metre
No
- Nominal voltage
750
- Nominal voltage U0
450 V
- Number-coded
No
- Test voltage
4000 V
- Cross section
3 G 1.5 mm²
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+80 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
JB-750 gelb
Documents & Downloads
Datasheet
Datasheet 1561318 HELU JB-750 Control lead 3 G 1.5 mm² Yellow 10334 100 m
User & Safety Instructions
User & Safety Instructions 1561318 HELU JB-750 Control lead 3 G 1.5 mm² Yellow 10334 100 m
