Name: HELU OZ-500 Orange Control lead 2 x 1 mm² Orange 10537 100 m
Brand: HELU
SKU: 1561321

An orange cable labelled 'HELUKABEL JZ-600'. Multi-core cable with coloured conductors visible.

Image similar

Product type

Control lead

No. of leads

2 x

Cross section (each core)

1 mm²

Cable type

OZ-500 Orange

Outside Ø

5.60 mm

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

PVC control cable

Technical specifications

Product type: Control lead

No. of leads: 2 x

Content: 100 m

Cross section (each core): 1 mm²

Cable features: Flexible

Cable type: OZ-500 Orange

Outside Ø: 5.60 mm

Packaged: Yes

Wire ID code: DIN VDE 0293 orange wires with consecutive black digit Imprint

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 7.5

Halogen-free: No

Manufacturer part #: 10537

Factory colour: Orange

Insulation material: PVC

Insulation: Special PVC

Core layout: Cu-blank, in accordance with BS 6360 Cl.5, IEC 60228 13

Material (details): PVC

Max. length sold by the metre: 500 m

Sold per metre: No

Nominal voltage: 500

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: 4000 V

Cross section: 2 x 1 mm²

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -15 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: OZ-500 orange
