Name: HELU TOPSERV® 119 Servo lead 4 G 4 mm² + 2 x 1 mm² Orange 707293 100 m
Brand: HELU
SKU: 2469474

Drawing of a cable cross-section next to a cable with orange insulation and the inscription 'HELKABEL TOPSERV 110 PVC-Oil'.

Image similar

Product type

Servo lead

No. of leads

4 G

Cross section (each core)

4 mm²

Cable type

TOPSERV® 119

Outside Ø

15.50 mm

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Cross-section (details) 4 G 4 + (2 x 1.0) C + (2 x 1.5) C
Number of wires Part 1/2/3: 4 G/2 x/2 x
Cross-section (each core) Part 1/2/3: 4.00 mm²/1.00 mm²/1.50 mm²
Wire insulation material part 1/2/3: PP/PP/PP
Conductor construction: Plain copper, fine strands according to DIN EN 60228, class 5

Product type: Servo lead

No. of leads: 4 G

Content: 100 m

Cross section (each core): 4 mm²

Cable features: Oil-resistant
Shielded
Flame-retardant

Cross section (each core) (part 2): 1 mm²

No. of leads (part 2): 2 x

Cable type: TOPSERV® 119

Outside Ø: 15.50 mm

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 15

Halogen-free: No

Manufacturer part #: 707293

Factory colour: Orange

Core layout: Plain copper, fine strand to DIN EN 60228, class 5

Material (details): PVC

Nominal voltage: 1000 V

Nominal voltage U0: 600 V

Test voltage: 4000 V

Cross section: 4 G 4 mm² + 2 x 1 mm²

Max. temperature range (flexible installation): +60 °C

Min. temperature range (flexible installation): 0 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -20 °C

Type: 707293
