Hensel 36000197 Cable gland with locknut, with strain relief, shockproof Plastic Black 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M32
Type
straight
Material
Plastic
Clamp Ø
12 mm
Highlights & Details
Hensel mounting cable socket ASS 32
Our service for you
Technical specifications
- Type of seal: Sealing ring that can be cut out
- Cable gland: no.
- Suitable for cable diameters of 12 to 21 mm
- Metric thread size 32
- Thread pitch 2 mm
- Surface: Untreated
- Hexagonal corner dimensions 40 mm
- Material quality: Polyamide (PA)
- Product type
Cable gland
- Features
with locknut
with strain relief
shockproof
- Factory colour
Black
- External thread
M32
- Type
straight
- Material
Plastic
- Clamp Ø
12 mm
- Terminal Ø (max.)
21 mm
- Thread length
10 mm
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP67
- Spanner size
36 mm
- Dimensions
40 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Dim
40
- RoHS-compliant
Yes
- Manufacturer part #
36000197
- Type
ASS 32
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2292261 Hensel 36000197 Cable gland with locknut, with strain relief, shockproof Plastic Black 1 pc(s)
Description
Mounting cable supports for pre-embossing M 32 and sealing range Ø 12-21 mm.
