Hensel 36001004 Ventilation plug with locknut, with strain relief, shockproof Plastic Light grey 1 pc(s)
Product type
Ventilation plug
External thread
M25
Type
straight
Material
Plastic
Clamp Ø
9 mm
EAN:
Part number:
Item no:
Technical specifications
- Type of seal: Sealing ring
- Cable gland: no.
- Suitable for cable diameters of 9 to 17 mm
- Metric thread size 25
- Thread pitch 2 mm
- Surface: Untreated
- Hexagonal corner dimensions 32 mm
- Material quality: Polyamide (PA)
- Product type
Ventilation plug
- Features
with locknut
with strain relief
shockproof
- Factory colour
Light grey
- External thread
M25
- Type
straight
- Material
Plastic
- Clamp Ø
9 mm
- Terminal Ø (max.)
17 mm
- Thread length
10 mm
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP67
- Spanner size
29 mm
- Dimensions
32 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Dim
32
- RoHS-compliant
Yes
- Manufacturer part #
36001004
- Type
KBM 25
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2296323 Hensel 36001004 Ventilation plug with locknut, with strain relief, shockproof Plastic Light grey 1 pc(s)
Description
Combined ventilation nozzle for pre-embossing M 25 and sealing range Ø 9-17 mm. For reducing condensation water by pressure compensation.
