Hensel 3600214 Cable gland with strain relief, shockproof Plastic Light grey 1 pc(s)
Product type
Cable gland
Type
straight
Material
Plastic
Clamp Ø
27 mm
Terminal Ø (max.)
35 mm
EAN:
Part number:
Item no:
Technical specifications
- Type of seal: Sealing ring
- Cable gland: no.
- Suitable for cable diameters of 27 to 35 mm
- Metric thread size: 50
- Thread pitch 2 mm
- Surface: Untreated
- Hexagonal corner dimensions 60 mm
- Material quality: Polyamide (PA)
- Product type
Cable gland
- Features
with strain relief
shockproof
- Factory colour
Light grey
- Type
straight
- Material
Plastic
- Clamp Ø
27 mm
- Terminal Ø (max.)
35 mm
- Thread length
10 mm
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP67
- Spanner size
55 mm
- Dimensions
60 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Dim
60
- RoHS-compliant
Yes
- Manufacturer part #
3600214
- Type
AKM 50
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2292256 Hensel 3600214 Cable gland with strain relief, shockproof Plastic Light grey 1 pc(s)
Description
Extension cable socket for pre-embossing M 50. Sealing range Ø 27-35 mm.
