IMG Stageline LS-280/SW 19" mixer No. of channels:8
EAN:
Part number:
Item no:
Technical specifications
- Line inputs, mono: 100 mV/15 kOhm
- Line outputs, mono: 1 V/100 Ohm
- Frequency range 20-20000 Hz
- Distortion factor:< 0.03%
- Signal-to-noise ratio: 70 dB, evaluates
- Power supply 230 VWechsel/50Hz/10VA
- Permissible operating temperature: 0-40°C
- Dimensions: 482 x 48 x 205 mm, 1 HE
- Weight: 2.3 kg
- Product type
19" mixer
- Channels
8
- No. of inputs
8 x
- Interfaces
Mic input combo jack (XLR, 6.35 mm jack)
6.3 mm jack out
XLR out
- No. of line-ins
8 x
- No. of microphone XLR inputs
8 x
- Weight
2.3 kg
- No of. XLR outputs
1 x
- Width
482 mm
- Height
48 mm
- Length
205 mm
- Dim
(L x W x H) 205 x 482 x 48 mm
Description
Features
- 8-way-line splitter
- 2 separate inputs
- Operating modes either:
- 1. Input A to 4 outputs,
- Input B to 4 outputs
- 2. Input A to 8 outputs
- XLR connections and gain controls for all inputs and outputs
- Signal and peak display for inputs via Duo-LED
- This text is machine translated.
