IMG Stageline STA-2000D PA amplifier RMS power per channel (at 4 Ohm): 500 W
EAN:
Part number:
Item no:
Technical specifications
- Output power:
- Sinusoidal power:
- 4 ohms: 4x500 WRMS4x580 WMAX
- 8 ohms: 4x280 WRMS4x310 WMAX
- 8 ohm bridge operation: 2x1000 WRMS2x1060 WMAX
- 4-ohm bridge operation: 2x1000 WRMS2x1060 WMAX
- Max. Output 2400 WMAX
- General:
- Inputs: 1 V/10 kOhm (XLR, bal.).1 V/5 kOhm (phono)
- Frequency range 20-20000 Hz
- Signal-to-noise ratio > : 119 dB, A"-rated
- Crosstalk attenuation: -
- Distortion factor < : 0.05 %
- Power supply 230 V AC/50 Hz/2320 VA
- Permissible operating temperature: 0-40 °C.
- Dimensions 482x335x89 mm, 2 HE
- Weight: 6.6 kg
- Connections: 1 x NEUTRIK-POWERCON4 x 3-pin-XLR4 x Cinch4 x NEUTRIK-type SPK 2 x NEUTRIK-type SPK Bridge"
- Product type
PA amplifier
- Power per channel (4Ω)
500 W
- Power per channel (8Ω)
280 W
- Max. frequency
20000 Hz
- Min. frequency
20 Hz
- Interfaces
RCA in
XLR in
SPK type socket
- Weight
6.6 kg
- Width
48.2 cm
- Height
8.9 cm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1332768 IMG Stageline STA-2000D PA amplifier RMS power per channel (at 4 Ohm): 500 W
Description
SOUNDCHECK 03/2015
"Musically act STA-1000D and 2000 D-wise inconspicuously STA-at a high level. Whether classical music, rock or language, the amplifier masters all disciplines without so much as."
Tools 4 music 01/2015
"The IMG Stage Line amps STA-2000D and STA-1000D impress through careful design and sophisticated selection of the internal components.
The low weight and the installation depth of only 335 mm is equally suitable for rack mounting as well as this series rack installation in the area.
The measured values are also use the hi-fi range is not.
The application of the "lightweight" i see at events in small to medium-sized entertainment area, as well as a multi-channel amplifier for conference and sprachbeschallungen for the stage monitor sound."
+ operating safety
+ weight
+ measuring results: low distortion values, untadeliger frequency response and noise voltage value
+ repair friendliness
+ protective circuits
+ very wide operating voltage range
+ processing
+ efficiency
- No XLR-Loop Through
This text is machine translated.
"Musically act STA-1000D and 2000 D-wise inconspicuously STA-at a high level. Whether classical music, rock or language, the amplifier masters all disciplines without so much as."
Tools 4 music 01/2015
"The IMG Stage Line amps STA-2000D and STA-1000D impress through careful design and sophisticated selection of the internal components.
The low weight and the installation depth of only 335 mm is equally suitable for rack mounting as well as this series rack installation in the area.
The measured values are also use the hi-fi range is not.
The application of the "lightweight" i see at events in small to medium-sized entertainment area, as well as a multi-channel amplifier for conference and sprachbeschallungen for the stage monitor sound."
+ operating safety
+ weight
+ measuring results: low distortion values, untadeliger frequency response and noise voltage value
+ repair friendliness
+ protective circuits
+ very wide operating voltage range
+ processing
+ efficiency
- No XLR-Loop Through
This text is machine translated.
Features
- The new generation of digital PA amplifiers from IMG Stage Line impresses with its rich performance and high energy efficiency.
- Quiet and light are also features that recommend this series for fixed installation as well as for mobile use.
- 4-channel PA digital amplifier
- Class-D concept
- Excellent acoustic performance
- Particularly high dynamic range with very low distortion factor
- Excellent pulse reproduction even in the bass range
- 482mm (19") rack mount, 2U
- 2 or 4 channels with bridge
- Silent operation by temperature-controlled fans, which only switch on from 85 °C.
- Lightweight design thanks to compact switched-mode power supply
- Energy-saving concept thanks to high efficiency
- 4 level controls
- Protective circuits against short-circuit, over-temperature, direct voltage at the output and overload
- LEDs for power, signal, bridge, oversteering (CLIP), overhead and protect
- Bridge mode
- Wide mains voltage range of 85-265 V change
- Type-SPK connections
