Isabellenhütte VMP-R010-1.0 VMP-R010-1.0 SMD resistor 10 mΩ SMD 2010 2 W 1 % 20 ppm/K 1 pc(s)
Product type
SMD resistor
Type
2010
Resistance
10 mΩ
Power rating
2 W
Tolerance ±
1 %
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 1.99 / piece)
€ 1.99
incl. VAT
Only 7 Piece(s) available
Highlights & Details
Resistance, metal foil, SMD 2010 (5025), 10 mΩ, 2 W, ±1 %, VMP-R010-1.0
Our service for you
Technical specifications
- Type SMD 2010 (5025)
- Width: 2.5 mm
- Height: 0.4 mm
- Length: 5.08 mm.
- Weight: 0.00003 kg
- Output: 2 W
- max. temperature: 170 °C
- min Temperature -65 °C.
- Ohm resistance 10 mΩ
- Technology: Metal foil
- Temperature coefficient ±20 ppm/K
- Tolerance: ± 1 %
- Product type
SMD resistor
- Type
SMD
- Type
2010
- Resistance
10 mΩ
- Power rating
2 W
- Tolerance ±
1 %
- Temperature coefficient
20 ppm/K
- Length
5.08 mm
- Width
2.5 mm
- Height
0.4 mm
- Content
1 pc(s)
- Dim
(L x W x H) 5.08 x 2.5 x 0.4 mm
- RoHS-compliant
Yes
- Type
VMP-R010-1.0
Documents & Downloads
Datasheet
Datasheet 3208051 Isabellenhütte VMP-R010-1.0 VMP-R010-1.0 SMD resistor 10 mΩ SMD 2010 2 W 1 % 20 ppm/K 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3208051 Isabellenhütte VMP-R010-1.0 VMP-R010-1.0 SMD resistor 10 mΩ SMD 2010 2 W 1 % 20 ppm/K 1 pc(s)
Description
SMD precision resistors design 2010 2.0 Watt tolerance 1.0 % series ISA PLAN type Isabellenhütte VMP. Can be used as a measuring resistor in power supply units, power modules, frequency converters, control units and power hybrids
This text is machine translated.
This text is machine translated.
