Joint bracket 09140160305 HARTING Content: 1 pc(s) Joint bracket
Product type
Joint bracket
Type
09 14 016 0305
Manufacturer part #
09140160305
Content
1 pc(s)
Inflammability class of insulation material according to UL94
Other
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Series: HAN-Modular®
- Temperature limit: -40 ... +125 °C
- Mating cycles ≥ 500
- Standards IEC 60664-1; IEC 61984
- Net weight: 66 g
- Features: Conductor cross-section PE (power side) 4 ... 10 mm²;Conductor cross-section PE (signal) 1 ... 2.5 mm².
- Material: Zinc-Druckguss
- Conductor cross-section: 6 mm²
- Accessory type: Joint frame
- Accessory description: For 4 modules;A ... D;2x PE 6 mm2
- Design size 16 B
- Approvals DNV GL
- Type
09 14 016 0305
- Product type
Joint bracket
- Manufacturer part #
09140160305
- Content
1 pc(s)
Other
500
Documents & Downloads
Datasheet
Datasheet 3008164 Joint bracket 09140160305 HARTING Content: 1 pc(s) Joint bracket
Datasheet 3008164 Joint bracket 09140160305 HARTING Content: 1 pc(s) Joint bracket
User & Safety Instructions
User & Safety Instructions 3008164 Joint bracket 09140160305 HARTING Content: 1 pc(s) Joint bracket
Description
Joint frames, for 4 modules, A ... D, 2x PE 6 mm2, size 16 B
