Joy-it com-lcd 16x2 Module 6.6 cm (2.6 inch) Compatible with (development kits): Arduino, Raspberry Pi® Backlighting
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
16 x 4 LCD module (green) auflotbar including pin strip
- Can be attached directly on the breadboard
- Suitable for EXP 500 Board (1503739)
- 16 pin connector configured
Technical specifications
- Display size: 16 character x 2 lines
- Background lighting: +5V DC LED backlight
- 16 pin header.
- Display technology
LCD
- Display (cm)
6.6 cm
- Screen size diagonal (inches)
2.6 inch
- Features
Backlighting
- Length
80 mm
- Width
36.5 mm
- Height
11 mm
- Compatible with
Arduino
Raspberry Pi®
Documents & Downloads
Datasheet
Datasheet 1656369 Joy-it com-lcd 16x2 Module 6.6 cm (2.6 inch) Compatible with (development kits): Arduino, Raspberry Pi® Backlighting
User & Safety Instructions
User & Safety Instructions 1656369 Joy-it com-lcd 16x2 Module 6.6 cm (2.6 inch) Compatible with (development kits): Arduino, Raspberry Pi® Backlighting
Description
This 16 characters/2 lines display is equipped with a 16-pin pin strip. It can be applied easily on your own projects.
It is compatible with breadboard and is therefore also suitable for experimental set-ups.
It is also compatible with the experimenting board EXP 500 (Article number: 1503739).
This text is machine translated.
It is compatible with breadboard and is therefore also suitable for experimental set-ups.
It is also compatible with the experimenting board EXP 500 (Article number: 1503739).
This text is machine translated.
Scope of delivery
- LCD module
