Joy-it SBC-OLED01.3 Module 3.3 cm (1.3 inch) 128 x 64 Pixel Compatible with (development kits): Arduino, Raspberry Pi®,
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 9.24
3
6% = € 0.53
€ 8.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 9.24 / piece)
€
Only 10 Piece(s) available
Highlights & Details
1.3" OLED display with SPI & I2C interface, 3.3 and 5V operation, 128x64 pixels (white)
- Operation possible via SPI and I2C3.3V and 5V operationApplication area: -40°C bid 85°C.Pixel color: White
Technical specifications
- Supply voltage: 3.3V / 5VLogic level: 3.3VDisplay driver: SHD1106Pixel color: WhiteOperating temperature -40°C to 85°C.
- Product type
Display
- Display technology
OLED
- Display (cm)
3.3 cm
- Screen size diagonal (inches)
1.3 inch
- Suitable for
Arduino Mega
Arduino Mega 2560
Arduino UNO
BBC micro:bit
Raspberry Pi® 3 B+
Raspberry Pi® 4 B
- Display resolution
128 x 64 Pixel
- Interfaces
SPI
I²C
- Brightness (min)
100 cd/m²
- Length
34 mm
- Width
36 mm
- Height
12 mm
- Compatible with
Arduino
Raspberry Pi®
ASUS Tinker Board
Banana Pi
C-Control
Calliope
LEGO® Education
LEGO® Technic
BBC micro:bit
Rock Pi
Documents & Downloads
Datasheet
Datasheet 2619578 Joy-it SBC-OLED01.3 Module 3.3 cm (1.3 inch) 128 x 64 Pixel Compatible with (development kits): Arduino, Raspberry Pi®,
User & Safety Instructions
User & Safety Instructions 2619578 Joy-it SBC-OLED01.3 Module 3.3 cm (1.3 inch) 128 x 64 Pixel Compatible with (development kits): Arduino, Raspberry Pi®,
Description
This 1.3" graphical OLED display has a resolution of 128 x 64 pixels and communicates via the SPI interface. Alternatively, the display on the back can also be soldered to the I2C interface. This makes the display particularly universally applicable.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Display module
