Joy-it XL6019 Step-up Converter Development board 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 3.61
10
7% = € 0.27
€ 3.34
25
11% = € 0.38
€ 3.23
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 3.61 / piece)
€
Highlights & Details
XL6019 Step-up voltage converter 5-35V DC
- Input voltage 5 to 35 volt
- Output voltage 5 to 40 volt (adjustable)
- 94% efficiency, power: Max. 20 W.
- Integrated MOSFET amplifier
- Input current: Up to 5A, output current max. 1.5A
Technical specifications
- Input voltage 5 to 40 volt
- Output voltage: 5 to 40 volts (adjustable via potentiometer)
- Efficiency: Up to 94%
- Output current 1.5 A/ 20 W
- Integrated MOSFET amplifier.
- Min. operating voltage
5 V
- Max. operating voltage
40 V
- Output voltage (max.)
40 V
- Output voltage (min.)
5 V
- Height
13 mm
- Width
28 mm
- Depth
50 mm
- Product type
Development board
Documents & Downloads
Datasheet
Datasheet 1697651 Joy-it XL6019 Step-up Converter Development board 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1697651 Joy-it XL6019 Step-up Converter Development board 1 pc(s)
User & Safety Instructions 1697651 Joy-it XL6019 Step-up Converter Development board 1 pc(s)
Information
Information 1697651 Joy-it XL6019 Step-up Converter Development board 1 pc(s)
Conformity certificate
Conformity certificate 1697651 Joy-it XL6019 Step-up Converter Development board 1 pc(s)
Description
High-performance DC/DC step-up converter with adjustable voltage regulator (XL6019). Ideal for simple and universal voltage adjustment. The small design of the controller allows it to be integrated into your projects. In the data sheet you will find a technical drawing which greatly simplifies the integration into your project.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Module
Hints
The input voltage cannot be undercut!
