JST S14B-PHDSS (LF)(SN) Built-in pin strip (precision) PHD series Total number of pins 14 Contact spacing: 2 mm
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
3
-
€ 0.75
9
8% = € 0.06
€ 0.69
15
12% = € 0.09
€ 0.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 3
Total (€ 0.75 / piece)
€
Highlights & Details
JST S14B-PHDSS (LF)(SN) Built-in pin strip (precision) PHD series Total number of pins 14 Contact spacing: 2 mm
- Content: 1 pc(s)
- No. of rows: 2
- Total number of pins: 14
Technical specifications
- Connector type
Pin strip, right angle
- Connector system
wire-to-board
- Series
PHD
- CS
2 mm
- Pins per row
7
- Total number of pins
14
- Pin Ø
0.5 mm
- Pin shape
Square
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Content
1 pc(s)
- Dim
(L x W x H) 15.9 x 5 x 8 mm
- Factory colour
Ecru
- Height
8 mm
- Length
15.9 mm
- Width
5 mm
- Industrial packaging
No
- Connection
Print
- Connector contact surface
Tin plated
- Board contact surface
Tin plated
- Connector orientation
Parallel (to the PCB)
- Manufacturer part #
S14B-PHDSS (LF)(SN)
- Type
S14B-PHDSS (LF)(SN)
- Material (details)
PA 66 UL94V-0
- Type
Angled connector strip
- Insulation material
Polyamide
- Nominal voltage (details)
250 V AC
- Nominal current (details)
3 A
- No. of rows
2
- Cross section
0.08 - 0.33 mm²
- Pins
2 x 7
- Connection
Crimp
- Contact material
Copper alloy
- Case material
Polyamide
- RoHS-compliant
Yes
- Product type
Built-in pin strip (precision)
Documents & Downloads
Datasheet
Datasheet 740908 JST S14B-PHDSS (LF)(SN) Built-in pin strip (precision) PHD series Total number of pins 14 Contact spacing: 2 mm
User & Safety Instructions
User & Safety Instructions 740908 JST S14B-PHDSS (LF)(SN) Built-in pin strip (precision) PHD series Total number of pins 14 Contact spacing: 2 mm
Description
2-row, detachable connection of cable to PCB. The catch bar casing allows an audible click when plugging in. A circular trough at the pin header ensures reverse voltage protection. Can be easily soldered thanks to pre-tinned pin header.
