Kemet 1 pc(s) MKP suppression capacitor Radial lead 0.15 µF 560 V DC, 275 V AC 20 % 15 mm (L x W x H) 18.0 x 6.0 x 12.0
Part number:
Item no:
Packaging type
Bulk
Product type
MKP suppression capacitor
Type
Radial lead
Capacity (elec.)
0.15 µF
Nominal voltage
560 V DC
275 V AC
Datasheet (PDF)
Number
Total (€ 0.3763 / piece)
€ 0.38
incl. VAT
14-day return policy included
Technical specifications
- ESD Packaging: No ESD
- Series R46
- Approvals: ENEC03, cULus, CQC
- Design_1: Radial
- Applications: Class X2 radio interference suppression applications for use in electromagnetic interference (EMI) suppression in cross-line applications requiring X2 safety classification. VIntended for use in situations where a capacitor failure would not result in an electrical shock. Not for use in "series connection with mains" applications.
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: • Winding technology, class X2
- • Polypropylenfolie dielectric, coating: Vacuum-metallized
- • Flame-retardant plastic casing (UL94V-0) with resin cast, no impregnation
- • damping arm
- • Low loss factor
- • High pulse load (dV/dt)
- • High insulation resistance
- Wire diameter 0.6 mm.
- Pitch_1:15 mm
- Climate category IEC 40/110/56
- Capacity 0.15 µF
- Capacity_1: 0.15
- Unit of capacity: µF
- Capacity Tolerance 20%
- Dielectric: Metallized PP film
- Nominal voltage DC 560 V
- Nominal voltage AC 275 V
- Pulse load 400 V/µs
- Class X2
- Insulation resistance_1: 100,000 MOhm
- Packaging type
Bulk
- Product type
MKP suppression capacitor
- Type
Radial lead
- Dim
(L x W x H) 18.0 x 6.0 x 12.0 mm
- Capacity (elec.)
0.15 µF
- Nominal voltage
560 V DC
275 V AC
- Flank steepness
400 V/µs
- Tolerance ±
20 %
- Material
Polypropylene
- Connection
THT
- Length
18.0 mm
- Width
6.0 mm
- Height
12.0 mm
- CS
15 mm
- Min. temperature
-40 °C
- Max. temperature
110 °C
- Content
1 pc(s)
- Cable Ø
0.6 mm
- RoHS-compliant
Yes
- Type
R46KI315000M2M
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3523518 Kemet 1 pc(s) MKP suppression capacitor Radial lead 0.15 µF 560 V DC, 275 V AC 20 % 15 mm (L x W x H) 18.0 x 6.0 x 12.0
User & Safety Instructions
User & Safety Instructions 3523518 Kemet 1 pc(s) MKP suppression capacitor Radial lead 0.15 µF 560 V DC, 275 V AC 20 % 15 mm (L x W x H) 18.0 x 6.0 x 12.0
Description
MKP suppression capacitors class X2 2
