Name: Kern MPC 300K-1LM Bathroom scales MPC 300K-1LM Weight range=300 kg
Brand: Kern
SKU: 3776637

Large industrial floor scale with separate digital display showing 00, used for weighing heavy items.

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Scales Kern MPC 300K-1LM

Compact bathroom scales with medical approval for professional use in medical diagnostics, optionally with calibration
This text is machine translated.

Technical specifications

Calibration value [e]: 0.1 kg
Class of calibration / accuracy class III.
Minimum weight [Min]: 2 kg
Reproducibility 0.1 kg
Linearity: ± 0.1 kg
Weighing system: Stretch measurement strips
Start-up time 3 seconds
Material housing: Steel, painted
Dimensions completely mounted (WxTxH) 500×455×120 mm
Material weighing plate: Plastic
Weighing platform dimensions (WxTxH) 500×455×120 mm
Display type: LCD
Display digit height: 25 mm
Units: Kg
Power supply included: Power supply & battery function (battery not included)
Battery type: Alkaline(-manganese)
Battery optional: Battery optional - internal
Battery charging time 12 h
Battery life - backlight on 20 hours
Battery life - backlight off: 40 hours
Auto-Off Interval(s) in battery/rechargeable battery mode: 3 min,5 min,30 min,15 min.
Battery 6×1.5 V AA
Battery life 20 h
Input voltage power supply unit / current [Max]: 100 V - 240 V, 50 / 60 Hz
Mains adapter/adapter for countries. Included in delivery: EURO,UK,CH
Mains power supply/adapter for countries - Optional: EURO,FROM,UK,US,CH
Wall power supply type: Wall power supply
Power supply included: Yes / No: Yes
Battery included: Yes / No: No.
Battery included: Yes / No: No.
Interfaces: RS-232 (optional, factory)

Product type: Bathroom scales

Weight range: 300 kg

Dim: (W x H x D) 500 x 120 x 455 mm

Weight: 11000 g

Weighing plate: Plastic

Width: 500 mm

Height: 120 mm

Depth: 455 mm

Series: MPC

Readability: 100 g

Accuracy class: III

Max. ambient temperature: 40 °C

Min. ambient temperature: -10 °C

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3776637 Kern MPC 300K-1LM Bathroom scales MPC 300K-1LM Weight range=300 kg

User & Safety Instructions

User & Safety Instructions 3776637 Kern MPC 300K-1LM Bathroom scales MPC 300K-1LM Weight range=300 kg

Information

Information 3776637 Kern MPC 300K-1LM Bathroom scales MPC 300K-1LM Weight range=300 kg

Features

Calibration class III (optional)
Medical approval according to VO (EU) 2017/745
The bestseller for the doctors' offices, pharmacies and hospitals
Rugged design for daily use in professional environments
Hygienic and easy to clean
Safe and skid-free set-up with height-adjustable rubber feet
Level for accurate leveling of scale in series
Version with [Max] = 300 kg and larger weighing plate. Particularly suitable for weighing obese patients. Sturdy handle for transporting the scales
Signal processing unit can be set in various positions, e.g. free standing or screwed to the wall. Wall bracket for mounting the evaluation device as standard
Large tread surface with non-slip and abrasion-resistant plastic surface for optimal patient stability
Fine display: By pressing a button the readability [d] can be increased by 1 digit for 5 s.
BMI function for determining the excess weight/normal weight/excess weight
Hold function: In the case of unstable patients, a stable weighing value is determined and "frozen" by means of mean value formation. This leaves enough time to devote to the patient and then read off the weighing value
Parent-child function: The weight of the parent determined by weighing is set to zero by pressing a button. The parent is then weighed together with the child. The weight of the child will now be shown directly on the display. Especially comfortable for infants, who can be weighed safely and securely on the arm of the parent
GLP/ISO protocol, printout of weighing value, BMI etc. with date and time. FLP-/GMP-compliant printing form in the languages DE, EN, FR, only in conjunction with RS-232 interface cable Kern CFS-A01 + MPC-A01 and printer Kern YKB-01N
Battery and mains operation possible, rechargeable battery mode optional
Occupational health and safety hood included in the delivery;
