Klauke 584R10BK Ring terminal 4x screw Cross section (max.)=25 mm² Hole Ø=10 mm Not insulated 1 pc(s) Piece
Packaging type
Piece
Product type
Ring terminal
Thread size
M10
Hole Ø
10 mm
Insulation type
Not insulated
EAN:
Part number:
Item no:
Highlights & Details
Terminal lug 16-25qmm
- 16 - 25 mm²
Technical specifications
- Nominal cross-section copper. Right: 16-25 mm²
- Nominal cross-section copper. RM: 16-25 mm²
- Material of the conductor: Copper
- With tear-off head: No.
- Surface protection: Plain
- Packaging type
Piece
- Product type
Ring terminal
- Thread size
M10
- Hole Ø
10 mm
- Insulation type
Not insulated
- Content
1 pc(s)
- Contact material
Copper
- Manufacturer part #
584R10BK
- Type
584R10BK
- max. cross section
25 mm²
- Min. cross section
16 mm²
- Cross-section range
16 - 25 mm²
- Features
4x screw
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3429519 Klauke 584R10BK Ring terminal 4x screw Cross section (max.)=25 mm² Hole Ø=10 mm Not insulated 1 pc(s) Piece
Description
For screwing conductors to VDE 0295 class 1 and 2, for example in lightning protection area Also for working outdoors. Material Cu-ETP, bare. 4 screws DIN 84 / DIN 933 bronze, F 60. 16 - 25 mm², M10, 4 screws.
