Klauke 65310 Ring terminal Anti-corrosive Cross section (max.)=16 mm² Not insulated 1 pc(s) Piece
Packaging type
Piece
Product type
Ring terminal
Thread size
M10
Insulation type
Not insulated
Content
1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Crimp terminal 16qmm insulated
- 16 - 16 mm²
Technical specifications
- Flange shape: Ring-shaped
- Flange length 23 mm
- Sleeve shape: Short
- Colour of the insulation: Blue
- Insulation: Without
- Total length 33 mm.
- Corresponds to DIN: No.
- For secure connections: No.
- Suitable for solid conductor: No.
- Suitable for multi-wire conductors: Yes
- Suitable for fine-wire conductors: Yes
- Suitable for high temperatures (up to 650 °C): No.
- Suitable for paint wire: No.
- Suitable for round wire: Yes
- Suitable for flat conductor: No.
- Bandware: No.
- Halogen-free: Yes
- Nominal cross-section: 16 mm²
- Bolt dimension (Imperial) 10
- Surface protection: Tin-plated
- Packaging type
Piece
- Product type
Ring terminal
- Thread size
M10
- Insulation type
Not insulated
- Content
1 pc(s)
- Contact material
Copper silver plated
- Manufacturer part #
65310
- Type
65310
- max. cross section
16 mm²
- Min. cross section
16 mm²
- Insulation material
Polyamide
- Dimensions
33 mm
- Cross-section range
16 - 16 mm²
- Features
Anti-corrosive
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3430393 Klauke 65310 Ring terminal Anti-corrosive Cross section (max.)=16 mm² Not insulated 1 pc(s) Piece
Description
For conductors such as VDE 0295 standard, class 2, 5 and 6. High-quality hard soldering process in crimping. PA insulation sleeve, halogen-free, with Easy-Entry cable entry. Dimensions in the conductor connection area according to DIN 46234. Grooved profile for improved contact characteristics. Cross section-dependent color coding Temperature resistance up to 105 ° C. Galvanically tin-plated for protection against corrosion. Material Cu-ETP.
