Name: LAPP 1030612/1000 Data transfer cable UNITRONIC® LiYCY (TP) Black 1000 m
Brand: LAPP
SKU: 3351436

A black cable with exposed copper wires at one end, marked with 'Lappkabel Stuttgart UNITRONIC® LiYCY (TP)'.

Cross-section of a coaxial cable: Multiple coloured cores with central conductors, surrounded by rings and an outer sheath.

1/2

Image similar

Product type

Data transfer cable

Cable type

UNITRONIC® LiYCY (TP)

Outside Ø

7 mm

Factory colour

Black

Content

1000 m

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Data transfer cable

Cable type: UNITRONIC® LiYCY (TP)

Outside Ø: 7 mm

Factory colour: Black

Content: 1000 m

Manufacturer part #: 1030612/1000

Insulation material: Polyvinyl chloride

Min. temperature range (fixed installation): -40 °C

Max. temperature range (fixed installation): 80 °C

Type: UNITRONIC® LiYCY (TP) 4x2x0,25 BK

: TRUE

: 0.25 mm²

: Polyvinyl chloride (PVC)

: Black

: Copper

: Polyvinyl chloride (PVC)

: -40-80 °C

: 7.6 mm

: Bare

: 114.0 mm

: 45.6 mm

: Other

: Other

: Round

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 3351436 LAPP 1030612/1000 Data transfer cable UNITRONIC® LiYCY (TP) Black 1000 m

User & Safety Instructions

User & Safety Instructions 3351436 LAPP 1030612/1000 Data transfer cable UNITRONIC® LiYCY (TP) Black 1000 m

Description

UNITRONIC ® LiYCY (TP) 4x2x0.25 BK low-frequency data cable; 4x2x0.25; conductor color code: DIN 47100; PVC; shielded; flexible

This text is machine translated.

Description

UNITRONIC ® LiYCY (TP) 4x2x0.25 BK low-frequency data cable; 4x2x0.25; conductor color code: DIN 47100; PVC; shielded; flexible
