Name: LAPP 21700151 ETHERLINE GUARD PM02TWA Industrial Ethernet monitor 100 MBit/s
Brand: LAPP
SKU: 2619769

A two-data port Ethernet monitoring device with an antenna. Label reads: 'LAPP ETHERLINE® GUARD PM02TWA'.

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Industrial Ethernet monitor

LAN transfer rate: 100 MBit/s

Transfer rate: 100 MBit/s

Ethernet ports: 2

10/100/1000 Mbps ports: 2 x

Power supply (LOV): via terminal

Weight: 0.11 kg

Width: 48.5 mm

Height: 75.5 mm

Depth: 32 mm

Type: ETHERLINE GUARD PM02TWA

Interfaces: RJ45

: IP20

Operating voltage: 24 V DC

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2619769 LAPP 21700151 ETHERLINE GUARD PM02TWA Industrial Ethernet monitor 100 MBit/s

User & Safety Instructions

User & Safety Instructions 2619769 LAPP 21700151 ETHERLINE GUARD PM02TWA Industrial Ethernet monitor 100 MBit/s

Description

Increase in plant availability due to planned downtimes - reduced maintenance costs.Simple commissioning with automated parameterization ("teach-in" in a few seconds).Does not require a new data line or changes to the cable design; retrofit into the existing network structure is possible at any time.Reliable IIoT communication thanks to MQTT interface (for status/data evaluation, settings, WLAN configuration,Update etc.).UseFor monitoring the service life of a data line at risk of failure (e.g. function-critical data line in dynamicApplications).Suitable for data lines according to transmission standard 100BASE-TX (up to 100 Mbit/s) according to IEEE 802.3.Also suitable for EtherCAT, Ethernet/IP and 2-pair PROFINET applications.For use in the control cabinet (protection class IP 20).For use in Ethernet-based networks of automation technology.

This text is machine translated.
