Collection
LAPP 53017430 Cable gland with bend relief cone M20 Polyamide Silver-grey (RAL 7001) 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M20
Material
Polyamide
Clamp Ø
5 mm
Terminal Ø (max.)
12 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.34
10
7% = € 0.17
€ 2.17
25
10% = € 0.24
€ 2.10
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.34 / piece)
€ 2.85
-18 %
€
Highlights & Details
LAPP 53017430 Cable gland with bend relief cone M20 Polyamide Silver-grey (RAL 7001) 1 pc(s)
- PA6 plastic cable gland with conical trumpet-shaped
Technical specifications
- Product type
Cable gland
- Features
with bend relief cone
- Factory colour
Silver-grey (RAL 7001)
- External thread
M20
- Material
Polyamide
- Clamp Ø
5 mm
- Terminal Ø (max.)
12 mm
- Thread length
13 mm
- Min. temperature
-20 °C
- Max. temperature
+100 °C
IP68
- Spanner size
24 mm
- Halogen-free
No
- Content
1 pc(s)
- Dim
- RoHS-compliant
Yes
- Manufacturer part #
53017430
- Type
SKINTOP® BT-M 20 x 1.5
- Material (details)
Body: Polyamide, seal: CR/NBR
- Temperature range
-20 - +100 °C
Variants(All information is without VAT, plus shipping costs)
Clamp Ø
Terminal Ø (max.)
External thread
LAPP 53017430 Cable gland with bend relief cone M20 Polyamide Silver-grey (RAL 7001) 1 pc(s)
This article
5 mm
12 mm
M20
Minimum order quantity: 1
Multiple: 1
€ 2.34*
LAPP 53017420 Cable gland with bend relief cone M16 Polyamide Silver-grey (RAL 7001) 1 pc(s)
3.5 mm
8 mm
M16
Minimum order quantity: 1
Multiple: 1
€ 1.67*
LAPP 53017440 Cable gland with bend relief cone M25 Polyamide Silver-grey (RAL 7001) 1 pc(s)
9 mm
14 mm
M25
Minimum order quantity: 1
Multiple: 1
€ 2.09*
LAPP 53015430 Cable gland with bend relief cone PG13.5 Polyamide Silver-grey (RAL 7001) 1 pc(s)
5 mm
12 mm
PG13.5
Minimum order quantity: 1
Multiple: 1
€ 2.51*
LAPP 53015440 Cable gland with bend relief cone PG16 Polyamide Silver-grey (RAL 7001) 1 pc(s)
9 mm
14 mm
PG16
Minimum order quantity: 1
Multiple: 1
€ 1.92*
LAPP 53015450 Cable gland with bend relief cone PG21 Polyamide Silver-grey (RAL 7001) 1 pc(s)
13 mm
18 mm
PG21
Minimum order quantity: 1
Multiple: 1
€ 3.35*
Documents & Downloads
Datasheet
Datasheet 526958 LAPP 53017430 Cable gland with bend relief cone M20 Polyamide Silver-grey (RAL 7001) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 526958 LAPP 53017430 Cable gland with bend relief cone M20 Polyamide Silver-grey (RAL 7001) 1 pc(s)
Information
Information 526958 LAPP 53017430 Cable gland with bend relief cone M20 Polyamide Silver-grey (RAL 7001) 1 pc(s)
Description
The conical trumpet-shaped cable entry provides additional protection, since it supports flexible cables as they enter the gland.
Scope of delivery
- Locknut not included.
