1/3
Image similar
LAPP 53111420 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M20
Material
Polyamide
Clamp Ø
7 mm
Terminal Ø (max.)
13 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.75
10
8% = € 0.06
€ 0.69
25
12% = € 0.09
€ 0.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.75 / piece)
€ 1.84
-59 %
€
Highlights & Details
LAPP 53111420 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)
- The original: Metric plastic cable gland compliant with EN 50262 for rapid installation.
Technical specifications
- Product type
Cable gland
- Factory colour
Grey-white (RAL 7035)
- External thread
M20
- Material
Polyamide
- Clamp Ø
7 mm
- Terminal Ø (max.)
13 mm
- Thread length
9 mm
IP68 (up to 5 bar)
- Spanner size
25 mm
- Certification marks
nach EN 50262
- Halogen-free
No
- Content
1 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
53111420
- Type
SKINTOP® ST-M 20x1.5
- Material (details)
Body: Polyamide/seal: CR/NBR
Variants(All information is without VAT, plus shipping costs)
Clamp Ø
Terminal Ø (max.)
External thread
LAPP 53111420 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)
This article
7 mm
13 mm
M20
Minimum order quantity: 1
Multiple: 1
€ 0.75*
LAPP 53111470 Cable gland M63 Polyamide Grey-white (RAL 7035) 1 pc(s)
34 mm
45 mm
M63
Minimum order quantity: 1
Multiple: 1
€ 10.92*
LAPP 53111400 Cable gland M12 Polyamide Grey-white (RAL 7035) 1 pc(s)
3.5 mm
7 mm
M12
Minimum order quantity: 3
Multiple: 1
€ 0.57*
LAPP 53111410 Cable gland M16 Polyamide Grey-white (RAL 7035) 1 pc(s)
4.5 mm
10 mm
M16
Minimum order quantity: 3
Multiple: 1
€ 0.66*
LAPP 53111430 Cable gland M25 Polyamide Grey-white (RAL 7035) 1 pc(s)
9 mm
17 mm
M25
Minimum order quantity: 1
Multiple: 1
€ 1.50*
LAPP 53111440 Cable gland M32 Polyamide Grey-white (RAL 7035) 1 pc(s)
11 mm
21 mm
M32
Minimum order quantity: 1
Multiple: 1
€ 2.76*
LAPP 53111450 Cable gland M40 Polyamide Grey-white (RAL 7035) 1 pc(s)
19 mm
28 mm
M40
Minimum order quantity: 1
Multiple: 1
€ 4.61*
LAPP 53111460 Cable gland M50 Polyamide Grey-white (RAL 7035) 1 pc(s)
27 mm
35 mm
M50
Minimum order quantity: 1
Multiple: 1
€ 7.55*
Documents & Downloads
Datasheet
Datasheet 601231 LAPP 53111420 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 601231 LAPP 53111420 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)
Information
Information 601231 LAPP 53111420 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)
Description
For universal application in mechanical engineering, plant construction, measurement and regulation systems, automation and electrical engineering as well as robotics. A clamping range of between 3.5 and 45 mm can be covered with just eight sizes. Less sizes mean greater flexibility and less storage costs.
