Name: LAPP 53112882 Cable gland M16 Polyamide Black (RAL 9005) 1 pc(s)
Brand: LAPP
SKU: 602757
Availability: InStock

A grey plastic cable gland with four round openings at the top, suitable for secure cable fastening and connection.

A hand is securing a white cable gland to a metal housing with two holes.

A person pulls a plastic screw fitting through an opening in the wall. An arrow indicates the direction of pulling. A hand emphasises the significance of the procedure.

A hand is turning a cable gland to secure it to a device base. An arrow indicates the direction of rotation.

A grey cable is guided through a white seal into a wall. An arrow indicates the direction of the cable.

A hand pulls a cable through a white screw connection in the wall. An arrow indicates the direction of rotation for tightening. A plastic clamp secures the cable.

A torque wrench measures a torque of 3.0 Nm on a screw. A digital display shows the value.

Technical drawing of a mechanical component with annotations for dimensions, diameters, and key widths. Line and cross-sectional view.

1/8

Product type

Cable gland

External thread

M16

Material

Polyamide

Clamp Ø

4.5 mm

Terminal Ø (max.)

10 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Wed 4 Nov

250 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 1.99 / piece)

€ 1.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

LAPP 53112882 Cable gland M16 Polyamide Black (RAL 9005) 1 pc(s)

Innovative time-saving lock-nose system
World novelty
Up to 70 % time saving
Protection class IP68

Our service for you

Technical specifications

SW1 / SW2 mm: 19 / 22
Torque: 2.5 Nm

Product type: Cable gland

Factory colour: Black (RAL 9005)

External thread: M16

Bore diameter: 16,3 (-0,2) mm

Torque: 2.5 Nm

Material: Polyamide

Clamp Ø: 4.5 mm

Terminal Ø (max.): 10 mm

Thread length: 8 mm

Length: 42 mm

Min. temperature: -20 °C

Max. temperature: +100 °C

: IP68

Spanner size: 19 mm
22 mm

Certification marks: VDE / EN 50262 in preparation

Dimensions: (C x D x M) 42 x 8 x 16 mm

Halogen-free: No

Content: 1 pc(s)

Dim: (C x D x M) 42 x 8 x 16 mm

RoHS-compliant: Yes

Manufacturer part #: 53112882

Type: SKINTOP® CLICK 16

Material (details): Body :Special polyamide · Sealing: Special elastomer

Type: CLICK M16

Temperature range: -20 - +100 °C

Variants(All information include VAT, plus shipping costs)

Terminal Ø (max.)

Clamp Ø

Factory colour

External thread

LAPP 53112882 Cable gland M16 Polyamide Black (RAL 9005) 1 pc(s)

Item no:602757

Fast track dispatch on Wed 4 Nov

250 Piece(s)Conrad Electronic

This article

10 mm

4.5 mm

Black (RAL 9005)

M16

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.99^*

LAPP 53112686 Cable gland M16 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:604236

Fast track dispatch on Wed 4 Nov

784 Piece(s)Conrad Electronic

10 mm

4.5 mm

Grey-white (RAL 7035)

M16

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.79^*

LAPP 53112687 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:604248

Fast track dispatch on Wed 4 Nov

37 Piece(s)Conrad Electronic

13 mm

7 mm

Grey-white (RAL 7035)

M20

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.79^*

LAPP 53112688 Cable gland M25 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:604260

Fast track dispatch on Wed 4 Nov

67 Piece(s)Conrad Electronic

17 mm

9 mm

Grey-white (RAL 7035)

M25

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.79^*

LAPP 53112689 Cable gland M16 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:604272

Fast track dispatch on Wed 4 Nov

98 Piece(s)Conrad Electronic

7 mm

2 mm

Grey-white (RAL 7035)

M16

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.29^*

LAPP 53112690 Cable gland M20 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:604284

Fast track dispatch on Wed 4 Nov

136 Piece(s)Conrad Electronic

10 mm

5 mm

Grey-white (RAL 7035)

M20

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.49^*

LAPP 53112691 Cable gland M25 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:604296

Fast track dispatch on Wed 4 Nov

59 Piece(s)Conrad Electronic

13 mm

6 mm

Grey-white (RAL 7035)

M25

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 3.49^*

LAPP 53112692 Cable gland M12 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:458826

Fast track dispatch on Wed 4 Nov

219 Piece(s)Conrad Electronic

7 mm

3.5 mm

Grey-white (RAL 7035)

M12

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.29^*

LAPP 53112694 Cable gland M32 Polyamide Grey-white (RAL 7035) 1 pc(s)

Item no:458869

Fast track dispatch on Wed 4 Nov

100 Piece(s)Conrad Electronic

21 mm

11 mm

Grey-white (RAL 7035)

M32

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 4.29^*

LAPP 53112876 Cable gland M16 Polyamide Silver-grey (RAL 7001) 1 pc(s)

Item no:602960

Fast track dispatch on Wed 4 Nov

20 Piece(s)Conrad Electronic

10 mm

4.5 mm

Silver-grey (RAL 7001)

M16

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.99^*

Documents & Downloads

Datasheet

Datasheet 602757 LAPP 53112882 Cable gland M16 Polyamide Black (RAL 9005) 1 pc(s)

User & Safety Instructions

User & Safety Instructions 602757 LAPP 53112882 Cable gland M16 Polyamide Black (RAL 9005) 1 pc(s)

Information

Information 602757 LAPP 53112882 Cable gland M16 Polyamide Black (RAL 9005) 1 pc(s)

Description

Cable guide system according to EN 50262 for quick mounting. The most innovative cable guide system in the market for fastest and most flexible mounting, with all the tested features of our SKINTOP® cable connectors used worldwide.
Simply click-in – turn to the left – turn to the right - done. Result: fixed, centered, strain relieved and highest degree of protection in seconds.Specially developed for:
•Switch cabinet construction
•Measuring, control and electrical technology
•Automation technology
• System, apparatus construction
•Control construction

Advantage
• Up to 70% time saving
through innovative lock system
•Simple, free mounting in
every position
•Fewer parts, counter nut no
longer necessary
• Cannot be lost
• No thread required
•Vibration-protected
• Highest quality
Strain relief according to
EN50262

•IP68, hermetically sealed
SKINTOP® CLICK-R application
The innovative SKINTOP® CLICK-R with
reduction seal insert for sealing
smaller clamping area
Benefit 2
•Reliable sealing of small cable cross-sections
•Cable strain-relief EN50262
Further benefits see SKINTOP® CLICK
