LED2WORK Industrial LED indicator light TUBELED_40 II Basic-Line 3570 lm 100 ° 24 V DC Piece 1 pc(s)
Packaging type
Piece
Product type
Industrial LED indicator light
Operating voltage
24 V DC
Luminous flux (Φ)
3570 lm
IP rating
IP67/IP69K
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Packaging type
Piece
- Product type
Industrial LED indicator light
- Type
TUBELED_40 II Basic-Line
- Operating voltage
24 V DC
- Luminous flux (Φ)
3570 lm
- Radiation angle
100°
- Connection
M12 plug
IP67/IP69K
- Protection class
IP67
- RoHS-compliant
Yes
n.rel.
III
40 mm
None
DC
23-23 W
Aluminium
Screw-on plate
80-89
40 mm
1040 mm
29 mm
LED not exchangeable
20-24 V
IP67
TRUE
FALSE
5700-5700 K
23.1 W
3570 lm
White
155 lm/W
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3741738 LED2WORK Industrial LED indicator light TUBELED_40 II Basic-Line 3570 lm 100 ° 24 V DC Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3741738 LED2WORK Industrial LED indicator light TUBELED_40 II Basic-Line 3570 lm 100 ° 24 V DC Piece 1 pc(s)
Description
The TUBELED_40 II Basic-Line carries the same DNA as the TUBELED_40 II, but deliberately refrains from functions such as on/off interface and electrical chain. As a cost-optimized version, it complements the tried and tested lighting system with an economical solution for applications with reduced functional requirements. Externally identical, it is equipped with a specially adapted LED lamp, which provides reliable light output at attractive conditions. With seven new versions, the Basic-Line offers a robust machine lamp for all areas of application where functionality and economic efficiency are in the foreground.
