LED2WORK Industrial LED indicator light TUBELED_Element 17 W 2520 lm 100 ° 24 V DC (L x W x H) 715 x 40 x 29 mm 1 pc(s)
Product type
Industrial LED indicator light
Operating voltage
24 V DC
Power
17 W
Luminous flux (Φ)
2520 lm
IP rating
IP54
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
TUBELED_40 element DC, 715 mm, 24V DC, cascadable
- High-power LED chips for daylight white 5200-5700K - very brightRadiation angle 100° and good Ra >80 to very good color reproduction Ra >85Service life of LED > 50,000 to 60,000h (L80/B10)Versions with different connection options: 24V DC voltage, 24V DC and cascadable or 220-240V ACVersion DC: Direct supply voltage 24V DC and cascading via M12 connectors A-codedVersion AC: Fast, direct connection via M12 plug connector S-codedFade-out: Diffuser, sealed PMMA cover over LED chipsSealed against dust and water spray: IP54Heat dissipation via aluminum extruded profileCan be used in high ambient temperaturesMounting via separately available accessoriesMade in Germany
Technical specifications
- Angle of radiation: 100°Note: Electrical transmission wiring up to max. 8 A DC at ta max. +30 °C (7 A DC at ta max. 40 TO +40 °CConnection light: M12 A-codedConnected load lamp 24 V DC ± 10%LED mounting lamp typeMounting accessories: OptionalSpecial feature: Cascadable, high temperature resistantOperating temperature -30... +70 °CGross weight 1150 gDimmable: Optionally via accessoriesFade-out: Diffuser, PMMAColour reproduction (Ra): > 85Manufactured in: GermanyWeight: 890 gHeight [B] x width [C]: 29 mm x 40 mmLamp life > 60,000 hLamp power ~17 WLight output 145 lm/WLamp light current 2520 lmLength [A]: 715 mmSMD LED lampLight distribution: DirectMaterial cover: PMMA, frostedMaterial housing: Aluminium, plastic end capsTUBELED_40 element DC, cascadableRisk group (DIN EN 62471): Free groupProtection class: IP54Protection class III
- Product type
Industrial LED indicator light
- Type
TUBELED_Element
- LED features
splashproof
- Operating voltage
24 V DC
- Operating current
700 mA
17 W
- Min. colour temperature
5200 K
- Colour temperature (max.)
5700 K
- Luminous flux (Φ)
2520 lm
- Radiation angle
100°
- Connection
M12 plug
- Material
Aluminium
IP54
- Protection class
III
- Min. temperature
-30 °C
- Max. temperature
+70 °C
- Length
715 mm
- Width
40 mm
- Height
29 mm
- Dim
(L x W x H) 715 x 40 x 29 mm
n.rel.
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2861305 LED2WORK Industrial LED indicator light TUBELED_Element 17 W 2520 lm 100 ° 24 V DC (L x W x H) 715 x 40 x 29 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2861305 LED2WORK Industrial LED indicator light TUBELED_Element 17 W 2520 lm 100 ° 24 V DC (L x W x H) 715 x 40 x 29 mm 1 pc(s)
Description
LED surface-mounted lampTUBELED_40 elementAs much as necessary, as little as possible ...... To turn LED lights into a good LED machine and industrial light. The application areas of the TUBELED_40 element are primarily "dry" machines and systems, without chip firing, as well as cooling and lubricants. Harder production environments are covered by the TUBELED_40 II, which also contributes a large part of the components to the TUBELED_40 element and thus makes the luminaire interesting for users, in which a higher degree of protection is not important. Apart from this, the TUBELED_40 element with the indicated protection class IP54 is well positioned and all WAS has needed a good LED machine lamp in order to be able to be used in most workplaces without any restrictions.Here are two more unbeatable advantages of the TUBELED_40 element: The LED machine lamp is cheap and the aluminum housing with black end caps and matte LED cover just looks good.Benefits:Bright and flicker-free lighting, without UV and IR-portionGenerous light exit surface and 100° surface lightSlim casing and different lengthsQuick and easy dismantling and retrofitting of machines and systemsTemperature-resistant and splash-proofAlso for high ambient temperaturesElectrically chained variants (cascadable)Application areas:Plastic processing: Injection molding machines, extruders, blow molding machinesMetal processing: Micro-precision machines, eroding machines, punch automationWood workingEquipment for assembly and packagingUsed at all places where narrow installation conditions prevail
