LEDVANCE LED Driver Performance LED driver Constant voltage 30 W 1250 mA 24 V 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
LED Driver Performance
- Constant voltage
- 24 V
- 1250 mA
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Operating current
1250 mA
- Dim
(L x W x H) 148 x 40 x 32 mm
- Factory colour
Colourless
- Output voltage (max.)
24 V
- Output voltage (min.)
24 V
- Max. output current
1250 mA
- Output current (max.) - rounded
1.25 A
- Operating voltage
230 V
- Protection class
II
IP66
- Connection
Open end cable
- Max. power
30 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
1250 mA
- Input voltage (max.)
264 V
- Min. input voltage
198 V
- Weight
330 g
- Power (min.)
30 W
- Power range
30 up to 30 W
- Width
40 mm
- Height
32 mm
- Length
148 mm
- Max. temperature
+50 °C
- Min. temperature
-40 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2203210 LEDVANCE LED Driver Performance LED driver Constant voltage 30 W 1250 mA 24 V 1 pc(s)
Warranty Terms
Warranty Terms 2203210 LEDVANCE LED Driver Performance LED driver Constant voltage 30 W 1250 mA 24 V 1 pc(s)
Description
Optimized for operation with 24 V flexible LED light band. Very stable output power. Quick and easy installation through pre-wiring. High efficiency and reliability. Installation in very cold and hot environments.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Outdoor driver
- User manual.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
