Name: Lian Li SUP-01 Midi tower PC casing White
Brand: Lian Li
SKU: 3339213

Highlights & Details

Lian Li SUP-01 Midi tower PC casing

Compact 45 liter housing in black
Independent cooling in three chambers for optimum performance
Direct GPU cooling due to placement on the front of the chassis
Radiator for water cooling on the right side
Fan holder outside the case for VRM, DRAM and M.2 cooling
Includes three pre-installed 120 mm fans

Technical specifications

Material: Steel, hardened glass
Volume: 44.8 l
ATX, Micro ATX, ITX form factor
Pre-assembled PCIe 4.0 riser cable with ARGB strips
Supported GPU length 315 to 400 mm (286 to 315 mm with rotated mount)
Maximum CPU-cooler height 88.2 mm
Power supply: ATX (max. 220 mm)
Pre-installed fans: 3x 120 mm
Ventilation places:
Page 1: 3x 120 mm (pre-installed)
Page 2: 3x 120 mm or 2x 140 mm
Outer back 1x 120 mm
Radiator places:
1x 360 mm or 280 mm
Drive bays:
2 x 2.5" SSD or 2 x 3.5" HDD (drive cage)
2x 2.5" SSD (behind MB tray)
Expansion slots: 7 (for low profile cards), 4 (for standard riser cards)
I/O ports:
1x Power button
1 x Reset button
2x USB 3.0 type A
1x USB 3.1 type-C
1x 3.5 mm jack (4-pin, TRRS, audio-in/out)
1x RGB-color control button
1x RGB mode control button
Dust filter:
1x underside
1x front side
1x right side
1x top side

Product type: PC casing

Case type: Midi tower

Factory colour: White

Interfaces (front): Audio line in
Audio line out

6.4 cm (2.5") internal slots: 4

Width: 212 mm

Height: 534 mm

Depth: 403.45 m

Weight: 13.36 kg

Form factor: ATX
Micro-ATX
Mini-ITX

No. of USB type A 3.0 ports: 2 x

No. of USB 3.0 ports: 1 x

Wireless charging: No

Dim: (W x H x D) 212 x 534 x 403.45 mm

Keyboard layout: German, QWERTZ

UKCA: not relevant

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3339213 Lian Li SUP-01 Midi tower PC casing White

Description

Lian Li SUP-01: Minimum space requirements, maximum cooling
The Lian Li SUP-01 offers an excellent cooling performance at a low volume of 45 liters through its unique three-chamber design. The PC-housing is designed to efficiently integrate essential components like GPU, water cooling, PSU, mainboard, CPU and storage drives and thereby ensure an excellent thermal performance.

Optimised cooling: Three-chamber design and high-performance fans
The SUP-01 has a direct cooling of the GPU through its placement on the front of the casing. The optimal cooling of your CPU is improved by the option of mounting a radiator on the right side of the housing. This sucks in cold air through the rear opening and discharges the heat via the side panel. In addition, an additional fan bracket that can be mounted from a 120 mm fan cools the VRM, DRAM and M.2 areas, whereby the heat escapes through the upper mesh panel.

The chassis comes with three pre-installed 120 mm fans that provide an efficient basis for cooling core components. This makes the system ready to use immediately after installation of the main components and offers excellent low temperatures.

Flexibility and adaptability: The versatile options of the SUP-01 housing
The SUP-01 supports mainboards in ATX, Micro ATX and ITX format as well as ATX power supplies with a maximum length of 220 mm. The chassis features a pre-installed PCIe 4.0 riser cable with ARGB strips for appealing optics and enables both horizontal and vertical mounting of the GPU.

With space for up to four 2.5-inch SSDs or two 3.5-inch HDDs, the SUP-01 offers flexible storage options. The I/O panel on the left side of the chassis has two USB 3.0 ports, one type C USB connector, one audio jack, and color control buttons for RGB lighting.

This text is machine translated.

Features

Compact Midi Tower
Excellent air flow
45 liter capacity
Plenty of space for hardware
Integrated Riser cable

Hints

Note: The Lian Li SUP-01 offers a wide range of configuration options. For optimal use of the limited space, precise planning is required, especially when selecting the components and positioning them.

The housing is intended for graphic cards of min. 315 to max. 400 mm length, because they are specially attached.
