Name: Lumel B2 500A/60mV Shunt Test current 500 A Voltage drop (num.) 60 mV Shunt resistor 500A/60mV B2
Brand: Lumel
SKU: 1562758
Availability: InStock

A rectangular, metallic earthing cable connector with screw connections and three parallel bars; used for earthing.

Various electrical copper connections, consisting of metal plates and screws, demonstrate variations in size and form.

1/2

Image similar

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

2 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 83.99 / piece)

€ 83.99

incl. VAT

Only 2 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Product type: Shunt

Test current: 500 A

Accuracy class: 0.2

Dim: (L x W x H) 145 x 40 x 30 mm

Weight: 0.85 kg

Width: 40 mm

Height: 30 mm

Length: 145 mm

Voltage drop: 60 mV

Type: B2 500A/60mV

Connections: Screw terminals

Type: B

Mounting type: Screws

Connection: Screw terminals

Documents & Downloads

Datasheet

Datasheet 1562758 Lumel B2 500A/60mV Shunt Test current 500 A Voltage drop (num.) 60 mV Shunt resistor 500A/60mV B2

User & Safety Instructions

User & Safety Instructions 1562758 Lumel B2 500A/60mV Shunt Test current 500 A Voltage drop (num.) 60 mV Shunt resistor 500A/60mV B2

Description

In addition to the resistors are used to measure direct currents. The shunt resistor is a voltage proportional to the current, which then, for example, with a moving-coil instrument can be displayed. The resistances are required in Class 0.2 according to DIN 43 703. The shunt resistor flowing through transmission power generates a voltage drop with a parallel, the pre-measuring device is measured. In addition to the resistors are adjusted so that the nominal current an exactly defined voltage (60A for type B2) drops.
