MEAN WELL ELG-100-24-3Y LED transformer, LED driver Constant voltage, Constant current 96 W 4 A 24 V DC not dimmable, Su
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MEAN CORRUGATED ELG-100-24-3Y LED switching power supply 24 V/DC
- Constant voltage, Constant current
- 24 V DC
- 4 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 199 x 63 x 35.5 mm
- Factory colour
Metal
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Test mark
EN61000-3-2. Class C. EN55015. EN61347-1. EN61347-2-13. 6kV Surge Immunity Level IEC 61000-4-5
- Max. output current
4 A
- Output current (max.) - rounded
4 A
- Operating voltage
115 V AC
230 V AC
- Protection class
II
- LED driver features
not dimmable
Surge protection
Overvoltage
PFC circuit
Suitable for flammable surfaces
Outdoor
IP67
- Connection
Open end cable
- Max. power
96 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
4 A
- Input voltage (max.)
305 V AC
- Min. input voltage
100 V AC
- Weight
850 g
- Power (min.)
96 W
- Power range
96 up to 96 W
- Type
Synchronised
- Width
63 mm
- Height
35.5 mm
- Length
199 mm
- Max. temperature
90 °C
- Min. temperature
-40 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1645986 MEAN WELL ELG-100-24-3Y LED transformer, LED driver Constant voltage, Constant current 96 W 4 A 24 V DC not dimmable, Su
User & Safety Instructions
User & Safety Instructions 1645986 MEAN WELL ELG-100-24-3Y LED transformer, LED driver Constant voltage, Constant current 96 W 4 A 24 V DC not dimmable, Su
Information
Information 1645986 MEAN WELL ELG-100-24-3Y LED transformer, LED driver Constant voltage, Constant current 96 W 4 A 24 V DC not dimmable, Su
Warranty Terms
Warranty Terms 1645986 MEAN WELL ELG-100-24-3Y LED transformer, LED driver Constant voltage, Constant current 96 W 4 A 24 V DC not dimmable, Su
Description
The LED power supplies in IP67 Aluminum housing meet the standards EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13, and are thus used for LED lighting applications.
This text is machine translated.
This text is machine translated.
Features
- Metal housing
- Overload protection by circuit breaker (Hiccup), auto recovery
- Protected against short circuit, overload, over voltage
- For LED lighting applications
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13
- Corresponds to 6 kV surge immunity level IEC61000-4-5.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
