MEAN WELL ELG-100-54B-3Y LED transformer, LED driver Constant voltage, Constant current 96.12 W 1.78 A 27 - 54 V DC 3-in
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LED switching power supply ELG -100-54 B-3 Y
- Constant voltage, Constant current
- 27 - 54 V DC
- 1.78 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 199 x 63 x 35.5 mm
- Factory colour
Metal
- Output voltage (max.)
54 V DC
- Output voltage (min.)
27 V DC
- Max. output current
1.78 A
- Output current (max.) - rounded
1.78 A
- Operating voltage
115 V AC
230 V AC
- Protection class
II
- LED driver features
3-in-1 dimmer
Suitable for flammable surfaces
Surge protection
Overvoltage
PFC circuit
Outdoor
IP67
- Connection
Open end cable
- Max. power
96.12 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
- Min. input voltage
100 V AC
- Weight
850 g
- Power range
96.12 W (max)
- Type
Synchronised
- Width
63 mm
- Height
35.5 mm
- Length
199 mm
- Max. temperature
90 °C
- Min. temperature
-40 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1645950 MEAN WELL ELG-100-54B-3Y LED transformer, LED driver Constant voltage, Constant current 96.12 W 1.78 A 27 - 54 V DC 3-in
User & Safety Instructions
User & Safety Instructions 1645950 MEAN WELL ELG-100-54B-3Y LED transformer, LED driver Constant voltage, Constant current 96.12 W 1.78 A 27 - 54 V DC 3-in
Information
Information 1645950 MEAN WELL ELG-100-54B-3Y LED transformer, LED driver Constant voltage, Constant current 96.12 W 1.78 A 27 - 54 V DC 3-in
Warranty Terms
Warranty Terms 1645950 MEAN WELL ELG-100-54B-3Y LED transformer, LED driver Constant voltage, Constant current 96.12 W 1.78 A 27 - 54 V DC 3-in
Description
The LED power supplies in IP67 Aluminum housing meet the standards EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13, and are thus used for LED lighting applications.
This text is machine translated.
This text is machine translated.
Features
- Metal housing
- Overload protection by circuit breaker (Hiccup), auto recovery
- Protected against short circuit, overload, over voltage
- For LED lighting applications
- 3 in 1 Constant current dimming function via 0 - 10 V/DC, 10 V PWM or external potentiometer
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13
- Corresponds to 6 kV surge immunity level IEC61000-4-5.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
