MEAN WELL HLG-240H-C700B LED driver Constant current 249.9 W 700 mA 178 - 357 V DC 3-in-1 dimmer, Suitable for flammable
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
HLG-240H-C700B
- Constant current
- 178 - 357 V DC
- 700 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 244.2 x 68 x 38.8 mm
- Factory colour
Aluminium
- Output voltage (max.)
357 V DC
- Output voltage (min.)
178 V DC
- Test mark
MM · UL · ENEC · CCC · CB ·
- Max. output current
700 mA
- Output current (max.) - rounded
700 mA
- Operating voltage
115 V AC
230 V AC
- Protection class
I
- LED driver features
3-in-1 dimmer
Suitable for flammable surfaces
Approved for use on furniture
Outdoor
PFC circuit
dimmable
Surge protection
Overvoltage
IP67
- Connection
Open end cable
- Max. power
249.9 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
- Min. input voltage
90 V AC
- Weight
1300 g
- Power range
249.9 W (max)
- Type
Pulsed
- Width
68 mm
- Height
38.8 mm
- Length
244.2 mm
- Max. temperature
90 °C
- Min. temperature
-40 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1838070 MEAN WELL HLG-240H-C700B LED driver Constant current 249.9 W 700 mA 178 - 357 V DC 3-in-1 dimmer, Suitable for flammable
User & Safety Instructions
User & Safety Instructions 1838070 MEAN WELL HLG-240H-C700B LED driver Constant current 249.9 W 700 mA 178 - 357 V DC 3-in-1 dimmer, Suitable for flammable
Warranty Terms
Warranty Terms 1838070 MEAN WELL HLG-240H-C700B LED driver Constant current 249.9 W 700 mA 178 - 357 V DC 3-in-1 dimmer, Suitable for flammable
Description
With the Power Supplies HLG-240H-C for LED lighting applications rounds off the output power of the HLG mean corrugated-C-Family on 240 W upwards.
The series HLG-240H-C with constant power are protected against short circuit, overvoltage and overheating.
The A-version of the power supply has an IP65 metal housing and the constant current is via an internal potentiometer can be set. The B-version comes in the IP67 metal housing and has a 3 in 1 dimming function.
The power supply units follow the powerful and reliable design of the HLG-C family
This text is machine translated.
The series HLG-240H-C with constant power are protected against short circuit, overvoltage and overheating.
The A-version of the power supply has an IP65 metal housing and the constant current is via an internal potentiometer can be set. The B-version comes in the IP67 metal housing and has a 3 in 1 dimming function.
The power supply units follow the powerful and reliable design of the HLG-C family
This text is machine translated.
Features
- Independent operating device
- Universal input
- Metal housing
- Constant current
- IP67, 3 in 1 dimming function, constant current adjustable 0...10 V DC, 10 V PWM signal and resistance
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- For LED lighting applications
- Typical life over 62,000 hours
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
