Image similar
MEAN WELL LED driver Constant voltage, Constant current 240.3 W 2.23 - 4.45 A 50 - 57 V DC 3-in-1 dimmer, Outdoor, dimma
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MEANWELL LED switched-mode power supply series HLG-240H Metal Case IP65 Single Output CV+CC (Mixed Mode) Power: 240W
- Constant voltage, Constant current
- 50 - 57 V DC
- 2.23 - 4.45 A
Technical specifications
- Mixed mode output (voltage stabilized/CV or current stabilized/CC)
- Depending on the connected LED illuminant (constant current or constant voltage), the fits
- DC output of the LED power supply, within the framework of the specified technical parameters of the data sheet, the load.
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 244.2 x 68 x 38.8 mm
- Factory colour
Metal
- Output voltage (max.)
57 V DC
- Output voltage (min.)
50 V DC
- Test mark
SELV, UL, EAC, CB
- Max. output current
4.45 A
- Output current (max.) - rounded
4.45 A
- Operating voltage
230 V AC
115 V AC
- Protection class
I
- LED driver features
3-in-1 dimmer
Outdoor
dimmable
adjustable
Overvoltage
Surge protection
PFC circuit
IP65
- Connection
Open end cable
- Max. power
240.3 W
- No. of outputs
1 x
- Output current (min.)
2.23 A
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
90 V AC
127 V DC
- Weight
1300 g
- Power range
240.3 W (max)
- Type
Pulsed
- Width
68 mm
- Height
38.8 mm
- Length
244.2 mm
- Max. temperature
+90 °C
- Min. temperature
-40 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2246178 MEAN WELL LED driver Constant voltage, Constant current 240.3 W 2.23 - 4.45 A 50 - 57 V DC 3-in-1 dimmer, Outdoor, dimma
User & Safety Instructions
User & Safety Instructions 2246178 MEAN WELL LED driver Constant voltage, Constant current 240.3 W 2.23 - 4.45 A 50 - 57 V DC 3-in-1 dimmer, Outdoor, dimma
Warranty Terms
Warranty Terms 2246178 MEAN WELL LED driver Constant voltage, Constant current 240.3 W 2.23 - 4.45 A 50 - 57 V DC 3-in-1 dimmer, Outdoor, dimma
Description
Features
- Output voltage and current limitation adjustable via internal potentiometer, dimming via implemented control cable, 3 in 1 dimming function (1...10V DC, PWM, 100k ohm potentiometer)
- Constant current
- Independant operating device
- Wide-range input
- Metal housing
- Overload protection through current limitation, auto recovery
- Protected against short-circuit, overload, overvoltage, overtemperature
- Built-in PFC circuit
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
