Image similar
MEAN WELL LED driver EEC G (A - G) Constant voltage, Constant current 150.2 W 3.13 A 48 V DC Suitable for flammable surf
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MEANWELL LED switched-mode power supply series ELG-150 Metal Case IP65, IP67 Single Output CV+CC (Mixed Mode), DALI Power: 150W
- Constant voltage, Constant current
- 48 V DC
- 3.13 A
Technical specifications
- Mixed mode output (voltage stabilized/CV or current stabilized/CC)
- Depending on the connected LED illuminant (constant current or constant voltage), the fits
- DC output of the LED power supply, within the framework of the specified technical parameters of the data sheet, the load.
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 219 x 63 x 35.5 mm
- Factory colour
Metal
- Output voltage (max.)
48 V DC
- Output voltage (min.)
48 V DC
- Test mark
SELV, UL, MM, ENEC, CB
- Max. output current
3.13 A
- Output current (max.) - rounded
3.13 A
- Operating voltage
230 V AC
115 V AC
- LED driver features
Suitable for flammable surfaces
Approved for use on furniture
Outdoor
PFC circuit
not dimmable
Surge protection
Overvoltage
IP67
- Connection
Open end cable
- Max. power
150.2 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
3.13 A
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
100 V AC
142 V DC
- Weight
950 g
- Power (min.)
105 W
- Power range
105 up to 150.2 W
- Type
Pulsed
- Width
63 mm
- Height
35.5 mm
- Length
219 mm
- Max. temperature
+90 °C
- Min. temperature
-40 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2237789 MEAN WELL LED driver EEC G (A - G) Constant voltage, Constant current 150.2 W 3.13 A 48 V DC Suitable for flammable surf
User & Safety Instructions
User & Safety Instructions 2237789 MEAN WELL LED driver EEC G (A - G) Constant voltage, Constant current 150.2 W 3.13 A 48 V DC Suitable for flammable surf
Warranty Terms
Warranty Terms 2237789 MEAN WELL LED driver EEC G (A - G) Constant voltage, Constant current 150.2 W 3.13 A 48 V DC Suitable for flammable surf
Description
With the ELG series from mean Well, we offer LED power supplies for you, which are characterized by their variety. The ELG series power supplies offer a setup time of less than 500 ms and a standby power consumption of less than 0.5 W.
This text is machine translated.
This text is machine translated.
Features
- Voltage and current are preset permanently
- protective conductor carried out in the primary cable
- Constant current, constant voltage
- Independant operating device
- Wide-range input
- Metal housing
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, excess temperature
- Built-in PFC circuit
- suitable for LED lighting applications
- SELV compliant
- corresponds to 6kV Surge Immunity Level
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
