Image similar
MEAN WELL LED transformer 155.4 W 1.05 A 74 - 148 V dimmable 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SNT IP65 155.4W 74-148V/1050mA cc DIMM.
- 74 - 148 V
- 1.05 A
Technical specifications
- Product type
LED transformer
- Dim
(L x W x H) 220 x 68 x 38.8 mm
- Output voltage (max.)
148 V
- Output voltage (min.)
74 V
- Test mark
MM-Zeichen
- Max. output current
1.05 A
- Output current (max.) - rounded
1.05 A
- Protection class
I
- LED driver features
dimmable
IP65
- Connection
Braid
- Max. power
155.4 W
- No. of outputs
1 x
- Input voltage (max.)
431 V DC
305 V AC
- Min. input voltage
127 V DC
90 V AC
- Weight
1040 g
- Power range
155.4 W (max)
- Width
68 mm
- Height
38.8 mm
- Length
220 mm
- Max. temperature
+90 °C
- Min. temperature
-40 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2900705 MEAN WELL LED transformer 155.4 W 1.05 A 74 - 148 V dimmable 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2900705 MEAN WELL LED transformer 155.4 W 1.05 A 74 - 148 V dimmable 1 pc(s)
Warranty Terms
Warranty Terms 2900705 MEAN WELL LED transformer 155.4 W 1.05 A 74 - 148 V dimmable 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
