Image similar
MEAN WELL LED Treiber LED driver Constant current 75 W 250 - 500 mA 75 - 150 V DC Suitable for flammable surfaces, Appro
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LED Treiber
- Constant current
- 75 - 150 V DC
- 250 - 500 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 180 x 63 x 35.5 mm
- Factory colour
Metal
- Output voltage (max.)
150 V DC
- Output voltage (min.)
75 V DC
- Test mark
UL, MM, ENEC, CB
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Operating voltage
115 V AC
240 V AC
- LED driver features
Suitable for flammable surfaces
Approved for use on furniture
Outdoor
PFC circuit
adjustable
not dimmable
Overvoltage
Surge protection
IP65
- Connection
Open end cable
- Max. power
75 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
250 mA
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
100 V AC
142 V DC
- Weight
800 g
- Power (min.)
60 W
- Power range
60 up to 75 W
- Type
Pulsed
- Width
63 mm
- Height
35.5 mm
- Length
180 mm
- Max. temperature
+85 °C
- Min. temperature
-40 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2237726 MEAN WELL LED Treiber LED driver Constant current 75 W 250 - 500 mA 75 - 150 V DC Suitable for flammable surfaces, Appro
User & Safety Instructions
User & Safety Instructions 2237726 MEAN WELL LED Treiber LED driver Constant current 75 W 250 - 500 mA 75 - 150 V DC Suitable for flammable surfaces, Appro
Warranty Terms
Warranty Terms 2237726 MEAN WELL LED Treiber LED driver Constant current 75 W 250 - 500 mA 75 - 150 V DC Suitable for flammable surfaces, Appro
Description
With the ELG series from mean Well, we offer LED power supplies for you, which are characterized by their variety. The ELG series power supplies offer a setup time of less than 500 ms and a standby power consumption of less than 0.5 W.
This text is machine translated.
This text is machine translated.
Features
- Current limitation can be set via internal potentiometer on the bottom of the housing
- Constant current
- protective conductor carried out in the primary cable
- Independant operating device
- Wide-range input
- Metal housing
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, excess temperature
- Built-in PFC circuit
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
