Image similar
MEAN WELL LED Treiber LED driver Constant voltage 600 W 12.5 A 48 V not dimmable 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SNT IP67 600W 48V/12.5A CV+CC
- Constant voltage
- 48 V
- 12.5 A
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Dim
(L x W x H) 280 x 144 x 48.5 mm
- Output voltage (max.)
48 V
- Output voltage (min.)
48 V
- Test mark
SELV; MM-Zeichen
- Max. output current
12.5 A
- Output current (max.) - rounded
12.5 A
- Protection class
I
- LED driver features
not dimmable
IP67
- Connection
Braid
- Max. power
600 W
- No. of outputs
1 x
- Output current (min.)
12.5 A
- Input voltage (max.)
431 V DC
305 V AC
- Min. input voltage
127 V DC
90 V AC
- Weight
3900 g
- Power (min.)
600 W
- Power range
600 up to 600 W
- Width
144 mm
- Height
48.5 mm
- Length
280 mm
- Max. temperature
+90 °C
- Min. temperature
-40 °C
- UKCA
not relevant
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2900677 MEAN WELL LED Treiber LED driver Constant voltage 600 W 12.5 A 48 V not dimmable 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2900677 MEAN WELL LED Treiber LED driver Constant voltage 600 W 12.5 A 48 V not dimmable 1 pc(s)
Warranty Terms
Warranty Terms 2900677 MEAN WELL LED Treiber LED driver Constant voltage 600 W 12.5 A 48 V not dimmable 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
