Name: MEAN WELL RDDW08F-12 DC/DC converter (module) 333 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Brand: MEAN WELL
SKU: 2143673
Availability: InStock

'MEAN WELL RSD-100B-15' Voltage Converter, Input Voltage: 9-36 VDC, Output: 15 VDC, Power: 100 W, Manufacturer: Schukat.

Datasheet (PDF)

Dispatches on Fri 16 Oct

10 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 24.99 / piece)

€ 24.99

incl. VAT

Only 10 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

MEANWELL DC/DC converter modules series RSDW08, RDDW08 DIP 24/DIL 24 case single and dual output input voltage ratio: 4:1 Power: 8 W Railway

In the DIP 24/DIL 24-housing
For direct PCB mounting
Input voltage range 4:1
No minimum load required
Input/output insulation 1500 V DC
Protection: short circuit (continuously), overload, over voltage and input voltage
Efficiency up to 86%
This text is machine translated.

Technical specifications

Product type: DC/DC converter (module)

Type: RDDW08F-12

Min. input voltage: 9 V DC

Input voltage (max.): 36 V DC

No. of outputs: 2 x

Max. output current: 333 mA

Output current (max.) - rounded: 333 mA

Efficiency (max.): 85 %

: 8 W

Insulation voltage: 1500 V DC

Connection: Pins

PSU features: DC-to-DC converter

Operating temperature (min.): -40 °C

Operating temperature (max.): +90 °C

Dim: (L x W x H) 31.8 x 20.3 x 10.2 mm

Height: 10.2 mm

Length: 31.8 mm

Width: 20.3 mm

RoHS-compliant: Yes

Output voltage (max.): 12 V DC
-12 V DC

Weight: 18.4 g

Content: 1 pc(s)

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

Datasheet

Datasheet 2143673 MEAN WELL RDDW08F-12 DC/DC converter (module) 333 mA 8 W No. of outputs: 2 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2143673 MEAN WELL RDDW08F-12 DC/DC converter (module) 333 mA 8 W No. of outputs: 2 x Content 1 pc(s)

Warranty Terms

Warranty Terms 2143673 MEAN WELL RDDW08F-12 DC/DC converter (module) 333 mA 8 W No. of outputs: 2 x Content 1 pc(s)

Features

In the DIP 24/DIL 24-housing
For direct PCB mounting
Input voltage range 4:1
No minimum load required
Input/output insulation 1500 V DC
Protection: short circuit (continuously), overload, over voltage and input voltage

Description

Features

In the DIP 24/DIL 24-housing
For direct PCB mounting
Input voltage range 4:1
No minimum load required
Input/output insulation 1500 V DC
Protection: short circuit (continuously), overload, over voltage and input voltage
