Name: MEAN WELL RSD-30G-5 DC/DC converter 12 V DC, 24 V DC, 36 V DC - 5 V DC/6 A 30 W
Brand: MEAN WELL
SKU: 1761271
Availability: InStock

'Metallic power supply, Model RSD-60L-5, with honeycomb ventilation. Includes connections and CE marking. Rectangular shape.'

Datasheet (PDF)

Fast track dispatch on Tue 27 Oct

90 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 32.99 / piece)

€ 32.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

DC/DC Converters

Meets ITE standards IEC60950-1, EN55022 and rail standard EN50155, EN45545-2 and IEC60571
Wide input voltage range
Suitable for harsh and very dusty environments with high vibrations and extreme temperatures

Technical specifications

Temperature range -40 to +85 °C

Input voltage: 9 -36 V

Product type: DC/DC converter

Used at: Indoors
Portable
Fixed

Output: Screw terminals

No. of outputs: 1 x

: 30 W

Input voltage: 12 V DC
24 V DC
36 V DC

Output voltage: 5 V DC

Connections: Screw terminals

Max. output current: 6 A

Output current (max.) - rounded: 6 A

Dim: (L x W x H) 113 x 60 x 25 mm

Weight: 250 g

Content: 1 pc(s)

Width: 60 mm

Height: 25 mm

Length: 113 mm

Type: RSD-30G-5

Efficiency: 85 %

UKCA: yes

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

Datasheet

Datasheet 1761271 MEAN WELL RSD-30G-5 DC/DC converter 12 V DC, 24 V DC, 36 V DC - 5 V DC/6 A 30 W

User & Safety Instructions

User & Safety Instructions 1761271 MEAN WELL RSD-30G-5 DC/DC converter 12 V DC, 24 V DC, 36 V DC - 5 V DC/6 A 30 W

Warranty Terms

Warranty Terms 1761271 MEAN WELL RSD-30G-5 DC/DC converter 12 V DC, 24 V DC, 36 V DC - 5 V DC/6 A 30 W

Description

Reliable and powerful DC/DC-converter. Meets ITE standards IEC60950-1, EN55022 and rail standard EN50155, EN45545-2 and IEC60571. Very compact design with wide input voltage range and built-in constant current limitation circuit. The highly efficient circuit design enables a very high degree of efficiency. The converter has a closed design and is connected by means of screw terminals. The converters are semi-sealed and can work between -40 and +70°C without forced cooling. Typical application areas are rail, bus, tram, subway, ship and many other in-car systems. It is also used for applications of two-stage insulation, voltage stability and industrial systems such as security systems, DC-UPS systems and telecommunications equipment. Suitable for harsh and very dusty environments with high vibrations and extreme temperatures.

This text is machine translated.

Features

Meets ITE standards IEC60950-1, EN55022 and rail standard EN50155, EN45545-2 and IEC60571
Ideal for in-car systems
Half enclosed
Wide input voltage range 4:1
No minimum load required
Closed design
Cooling by free air convection
Very compact and only 25 mm high
Input/output insulation 4 000 V/DC
Built-in constant current limitation circuit
Suitable for harsh and very dusty environments with high vibrations and extreme temperatures
Circuit breaker
Overload protection
High effect range
Low ripple and minimum noise
Input with reverse voltage protection
Highest EMC characteristics
Overvoltage protection
LED display

Scope of delivery

DC/DC Converters
User manual.
