MEAN WELL XLC-25-12-S LED driver Constant voltage 25.2 W 2.1 A 12 V Surge protection 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Mean Well XLC-25 LED-SNT plastic case
- Constant voltage
- 12 V
- 2.1 A
Technical specifications
- XLC-25 series
- Application: Lighting
- Dimensions: Length 147 mm
- Dimensions: Width 40 mm
- Dimensions: Height 32 mm
- Weight 180 g
- Identification: MM characters; SELV
- Min. Operating temperature -25 °C
- Max. operating temperature: 90 °C
- Storage temperature, min.: -40 °C.
- Storage temperature, max. 80 °C
- Min. Network frequency: 47 Hz
- Network frequency max. 63 Hz
- Min. Input voltage AC 100 V
- Max. Input voltage AC 305 V
- Min. Input voltage DC 141 V.
- Max. Input voltage DC 431 V.
- Input current 0.15 A
- Efficiency 86 %
- Idle power, less than 0.5 W
- Leakage current, max. 0.75 mA
- Inrush current, max. 10 A
- Power factor correction (PFC): 1
- Power factor 0.95
- Connector type, input: Plug-in terminal
- Number of outputs 1
- Power output: 25.2 W
- Output voltage 12 V
- Output voltage tolerance -4 - 4 %
- Remaining ripple 60 MVP-p
- Output current: 2.1 A
- Overload protection 1
- Overload protection version: Hiccup
- Short circuit protection 1
- Overvoltage protection 1
- Overtemperature protection 1
- Connector type, output: Plug-in terminal
- Protection class: II
- INSULATION VOLTAGE I/P-O/P 3,750 V
- CE, EN, IEC, EAC, UKCA, CCC,ENEC,RCM
- Standards (EMC) EN 55015
- Standards (security): EN 61347-1, EN 61347-2-13, IEC 61347-1, IEC 61347-2-13
- REACH-SVHC: No.
- WEEE (waste electronics): No.
- RoHS R - RoHS compliant
- Operating mode CV
- Dimmable:0
- Interfaces: Cannot be dimmed
- Number of max. B16 circuit breaker: 85
- Number of max. at C16 Circuit breaker: 85
- Output current selectable: 0
- Product type
LED driver
- Type
Constant voltage
- Operating current
0.15 A
- Dim
(L x W x H) 147.0 x 40.0 x 32.0 mm
- Output voltage (max.)
12 V
- Output voltage (min.)
12 V
- Test mark
MM-Zeichen. SELV. CE. EN. IEC. EAC. UKCA. CCC. ENEC. RCM
- Max. output current
2.1 A
- Output current (max.) - rounded
2.1 A
- Protection class
II
- LED driver features
Surge protection
- Connection
Plug & Clip
- Max. power
25.2 W
- No. of outputs
1 x
- Input voltage (max.)
305 V
- Min. input voltage
100 V
- Weight
180.0 g
- Power range
25.2 W (max)
- Width
40.0 mm
- Height
32.0 mm
- Length
147.0 mm
- Max. temperature
90 °C
- Min. temperature
-25 °C
- Operating temperature (max.)
90 °C
- Operating temperature (min.)
-25 °C
- Input voltage
431 V
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3164299 MEAN WELL XLC-25-12-S LED driver Constant voltage 25.2 W 2.1 A 12 V Surge protection 1 pc(s)
Warranty Terms
Warranty Terms 3164299 MEAN WELL XLC-25-12-S LED driver Constant voltage 25.2 W 2.1 A 12 V Surge protection 1 pc(s)
Description
DC-enabled, flicker-free, emergency light control device, independent operating device
This text is machine translated.
This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
