MENNEKES 6222282 CEE surface-mount splitter 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Contact material: CuSn
- Military version: No.
- Surface treatment contacts: Untreated
- CEE socket - 16 A: Without
- CEE socket - 32 A: Without
- CEE socket - 63 A: Without
- CEE socket - 125A: Without
- Security: Other
- Residual current type: Other
- FI-Safety switch: Other
- Material of the housing: Stainless steel
- Feed/connection options: Feed with connector
- Handling: Wall-mounting
- Product type
CEE surface-mount splitter
IP44
- Factory colour
Grey
- Dim
(W x H x D) 300 x 700 x 310 mm
- Width
300 mm
- Height
700 mm
- Content
1 pc(s)
- Depth
310 mm
Documents & Downloads
Datasheet
Datasheet 3856627 MENNEKES 6222282 CEE surface-mount splitter 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3856627 MENNEKES 6222282 CEE surface-mount splitter 1 pc(s)
Description
MENNEKES surface-mounted distributor as wall-mounted device protection IP 44 Housing: 1 stainless steel housing, 1.4301 ground, K240 700x300x310 mm (HxBxT) Mounting/connection possibility: 1 x CEE mounted plug-in devices 125A 5p 1h larger than 50V (IP 67) Terminal for 1 line up to 5 x 50mm² (flexible max. 35 mm²) Cable entry: 2 x cable entry grommet below, suitable for cable diameters from 13-43mm 1 x brass - locking screw M20 below front door with pivot lever handle and profile half cylinder can be locked with the coupling inserted; 1 grounding screw M6 inner 1 set wall mounting brackets (90432000) Total weight: approx. 30 KG
