Molex Built-in SIL socket (standard) Total number of pins 20 Contact spacing: 4.20 mm 874272042 1 pc(s) Bulk
Product type
Built-in SIL socket (standard)
CS
4.20 mm
Total number of pins
20
Packaging type
Bulk
Content
1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Molex 874272042 WTB VERT HDR
- Content: 1 pc(s)
- Total number of pins: 20
Our service for you
Technical specifications
- Packaging type
Bulk
- Product type
Built-in SIL socket (standard)
- CS
4.20 mm
- Total number of pins
20
- Content
1 pc(s)
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
874272042
- Connector contact surface
Tin plated
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Type
874272042
- Engineering Series Name
WTB VERT HDR
- Engineering Series No
87427
Documents & Downloads
Datasheet
Datasheet 2760471 Molex Built-in SIL socket (standard) Total number of pins 20 Contact spacing: 4.20 mm 874272042 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 2760471 Molex Built-in SIL socket (standard) Total number of pins 20 Contact spacing: 4.20 mm 874272042 1 pc(s) Bulk
Description
Mini-Fit Jr. Header, 4.20mm Pitch, Vertical, Nylon, without Flange, 20 Circuits, Tin (Sn) over Nickel (Ni) Plating, Bulk Packaging
