Monacor SA-230/SW PA amplifier RMS power per channel (at 4 Ohm): 25 W
EAN:
Part number:
Item no:
Technical specifications
- Output power:
- Maximum power: 2 x 50WMAX
- Sinusoidal power:
- Stereo 4 ohms: 2 x 25WRMS
- Stereo 8 ohms: 2 x 20 WRMS
- General information:
- Inputs: 175 mV/8 kOhm (Line) 2.5 mV/3.5 kOhm (Mic)
- Frequency range 20-20000 Hz
- Signal-to-noise ratio: 62 dB
- Digital echo: 200 ms
- Sound Control: Bass +/-10 dBHohen +/-10dB
- Power supply 230 VWechsel/50 Hz/150 VA
- Permissible operating temperature: 0-40°C
- Dimensions: 432 x 45 x 275 mm
- Weight: 4 kg.
- Connections: Line: RCA L/RMic: 6.3-mm jack erec: RCA L/RLS: LS-terminals
- Product type
PA amplifier
- Power per channel (4Ω)
25 W
- Power per channel (8Ω)
20 W
- Max. frequency
20000 Hz
- Min. frequency
20 Hz
- Interfaces
6.3 mm jack in
RCA in
Screw terminals
- Weight
4 kg
- Width
43.2 cm
- Height
4.5 cm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1332515 Monacor SA-230/SW PA amplifier RMS power per channel (at 4 Ohm): 25 W
Description
Features
- Universal Stereo mixer-amplifier sing with!
- The clearly structured user interface of the SA-230/SW invites you to listen to music and especially to make music.
- Each one of three stereo line and three mono microphone sources can easily be mixed together.
- In connection with special karaoke CDs/DVDs functions such as One-Touch-Karaoke" or "vocal partner" is available.
- The microphone channels as a adjustable digital echo can effect are mixed in
- The fan-less cooling concept of the amplifier provides for noiseless operation.
- Modern protection mechanisms offer safety in the event of overload, overheating and short-circuit
- 100WMAX
- Noiseless operation through fan-less cooling concept
- 3 stereo line inputs
- 3 mono microphone inputs, front, each with gain control
- Adjustable digital echo for the microphone inputs
- Karaoke function
- Vocal partner function
- LEDs for level and active line inputs
- Controls for volume, bass, treble, balance and digital echo
- Stereo Record output
- 482-mm-Rack Installation (19"), 1U, with supplied mounting angles"
- This text is machine translated.
Scope of delivery
- Mounting bracket
