MPE Garry Pin strip (standard) 155-1-010-0-F-BS0 1 pc(s) Piece
Packaging type
Piece
Product type
Pin strip (standard)
Connection
Soldering
Contact surface
Gold plated
Dim
(W x H x D) 17.0 x 8.6 x 5.5 mm
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
Pin header direct RM2,00
- Content 1 pc(s)
Our service for you
Technical specifications
- Soldibility 260 °C / 10 s
- Dielectric strength 500 V RMS
- Packaging type
Piece
- Product type
Pin strip (standard)
- Connection
Soldering
- Contact surface
Gold plated
- Dim
(W x H x D) 17.0 x 8.6 x 5.5 mm
- Manufacturer part #
155-1-010-0-F-BS0
- Content
1 pc(s)
- Width
17.0 mm
- Height
8.6 mm
- RoHS-compliant
Yes
- Max. temperature
260 °C
- Type
155-1-010-0-F-BS0
- Depth
5.5 mm
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-40 °C
Documents & Downloads
Datasheet
Datasheet 3735500 MPE Garry Pin strip (standard) 155-1-010-0-F-BS0 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3735500 MPE Garry Pin strip (standard) 155-1-010-0-F-BS0 1 pc(s) Piece
Description
For MPF_G series pin connectors (see note)
Gold-plated version
