OBO Bettermann 2013002 Cable gland Plastic Dark grey 50 pc(s)
Product type
Cable gland
External thread
M20
Type
Straight
Material
Plastic
Features
for ribbon cables
with seal
with cable feeder
EAN:
Part number:
Item no:
Technical specifications
- Metric thread type:
- Thread which large metric/PG: 20
- Untreated surface:
- Glass-fiber reinforced: no
- Impact: no
- Color: dark gray
- Bend protection: no
- With nut: no
- Multi-seal insert: no
- Flat cable gland: yes
- With strain relief: no
- Type of seal: sealing ring
- Product type
Cable gland
- Features
for ribbon cables
with seal
with cable feeder
- Factory colour
Dark grey
- External thread
M20
- Type
Straight
- Material
Plastic
- Min. temperature
-40 °C
- Max. temperature
+90 °C
IP31
- Spanner size
27 mm
- Halogen-free
Yes
- Content
50 pc(s)
- Manufacturer part #
2013002
- Type
106 FL M20 8 19
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1962778 OBO Bettermann 2013002 Cable gland Plastic Dark grey 50 pc(s)
Description
Flat cable entry in the twisting cap design, with metric connection thread according to IEC 432, Protection class IP 31, with pre-assembled nozzle sealing ring 107/F.
