OBO Bettermann 2022648 Cable gland 1.5 mm Plastic, PA 50 pc(s)
Product type
Cable gland
Type
Straight
Material
Plastic
PA
Clamp Ø
5 mm
Terminal Ø (max.)
12 mm
EAN:
Part number:
Item no:
Technical specifications
- Thread Type: PG
- Thread which large metric/PG 13.5
- Suitable for cable diameter: 5..12 mm
- Untreated surface:
- Glass-fiber reinforced: no
- Impact: no
- Color: Other
- Bend protection: no
- With nut: no
- Multi-seal insert: no
- Flat cable gland: no
- With strain relief: yes
- Type of seal: sealing ring
- Divisible cable gland: no
- Explosion tested design: no
- For Ex Zone Gas: without
- For Ex zone dust: without
- Product type
Cable gland
- Features
with strain relief
- Internal thread
1.5 mm
- Type
Straight
- Material
Plastic
PA
- Clamp Ø
5 mm
- Terminal Ø (max.)
12 mm
- Thread length
9 mm
- Min. temperature
-20 °C
- Max. temperature
+65 °C
IP68
- Spanner size
24 mm
- Halogen-free
Yes
- Content
50 pc(s)
- Manufacturer part #
2022648
- Type
V-TEC PG13.5 SGR
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1966739 OBO Bettermann 2022648 Cable gland 1.5 mm Plastic, PA 50 pc(s)
Description
Cable gland into domed cap design with a large sealing range as well as strain relief and anti-twist protection for high density claims, sealing ring made of chloroprene/nitrile rubber, molded sealing ribs, and therefore no connection thread-sealing ring is required, tested according to VDE 0619
