OBO Bettermann 2022672 Cable gland with strain relief, with seal PG29 Plastic 1 pc(s)
Product type
Cable gland
External thread
PG29
Type
straight
Material
Plastic
Clamp Ø
14 mm
EAN:
Part number:
Item no:
Highlights & Details
Our service for you
Technical specifications
- Thread pitch 1.41 mm
- Hexagonal width 47.5 mm
- Product type
Cable gland
- Features
with strain relief
with seal
- Factory colour
Grey
- External thread
PG29
- Type
straight
- Material
Plastic
- Clamp Ø
14 mm
- Terminal Ø (max.)
25 mm
- Thread length
11 mm
- Min. temperature
-20 °C
- Max. temperature
+65 °C
IP68
- Spanner size
42 mm
- Halogen-free
Yes
- Content
1 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
2022672
- Type
V-TEC PG29 SGR
Grey
Straight
TRUE
FALSE
7001
Untreated
42 mm
11 mm
TRUE
FALSE
Sealing ring
Polyamide (PA)
-20-65 °C
PG
Plastic
1.41 mm
FALSE
FALSE
FALSE
FALSE
47.5 mm
FALSE
14-25 mm
IP68
None
29
None
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3332570 OBO Bettermann 2022672 Cable gland with strain relief, with seal PG29 Plastic 1 pc(s)
